A/ TRANSMITTER
1. Functioning with batteries (not supplied)
Press the locking button and slide the battery compartment lid in the direction indicated. Insert 3 alkaline AAA
type batteries in the compartment. Respect the polarity indications (+/-). Close the cover.
N.B. For the best performances do not mix new and used or rechargeable and alkaline batteries.
2. Functioning on mains (mains adapter supplied)
The transmitter can be powered from a power point by using the
5 V adapter supplied.
Plug the adapter into the CC socket of the transmitter (10). Connect
the adapter to the mains power point. The power supply from the
batteries will be cut as soon as the 'transmitter is connected to
the mains.
NB. The transmitter has a longer range when it is powered from
the mains.
B/ RECEIVER
1. Functioning with the supplied battery
The Lithium-Polymer battery is already installed in the
receiver. To change the battery press on the locking
button and slide the compartment lid in the direction
indicated; take out the battery and disconnect the wire.
2. Charging the battery with the mains adapter
Connect the 5 V adapter plug to the receiver socket (21). The
battery recharges even if the receiver is off. When the receiver is on,
the bars of the charge indicator on the LCD screen flash repeatedly.
When the battery is fully charged all the bars are visible and stop
flashing. It is not necessary to disconnect the adapter from the
receiver; it does not harm the battery. When the battery loses its
charge and the voltage falls below a certain level the adapter
automatically starts to recharger again.
NB. Before using for the first time, charge the Lithium-Polymer
battery for at least 3 hours. It is recommended to switch the
appliance off when charging for the first time.
NB. To prolong the life of the battery wait for it to be fully uncharged before recharging it.
CONNECTING THE TRANSMITTER TO THE RECEIVER
Your transmitter and your receiver are already connected and ready to communicate. This babyphone can work
with several transmitters (up to 2). To connect an additional transmitter please go through the following stages.
1. Keep the button (13) ▼ on the receiver down.
All manuals and user guides at all-guides.com
POWER SUPPLY
BABYPHONE PREMIUM CARE • Instruction manual
