b. Use the buttons (12) (13) ▲▼ to configure the "Out of range" alert function; the configuration must be
identical to the transmitter's. If the configuration is different the alarm may go off for no reason or inversely
not go off at all even if the receiver is no longer in range of the transmitter. If the appliance is associated with
2 transmitters the configuration must be identical to that of the transmitter with the corresponding number.
or
c. Press the "Menu" button (14) to confirm the selection. (If you have selected
"On" the "Out of range" alert icon appears on the screen in normal mode). This
is what is displayed on the screen:
d. By means of the buttons (12) (13) ▲▼ set the maximum temperature above
which the appliance must set off an alarm. If you press the buttons briefly the
temperatures appear degree by degree in turn. If you keep the buttons (12)
(13) down the temperatures appear more rapidly. You can select temperatures
ranging from -3 °C to +50 °C. If you have selected "Off" no maximum
temperature is defined. Press the "Menu" button (14) to confirm the selection.
This is what is displayed on the screen:
e. By means of the buttons (12) (13) ▲▼, rset the minimum temperature below
which the appliance must set off an alarm. You can select temperatures
ranging from -8 °C to +44 °C or 2 °C below the maximum temperature chosen.
If you have selected "Off" no minimum temperature is defined. Press the "Menu" button (14) to confirm the
selection; the screen returns to normal mode.
f. Note that the maximum and minimum temperature configuration is identical for both transmitters.
g. In stand-by mode briefly press the "Menu" button (14) to display the configuration of the "Out of range" alert
and temperature alarm.
2. Place the receiver at a reasonable distance from the transmitter to avoid feedback. If the receiver is too close
the speaker may produce a strident sound (18).
3. When the receiver receivers a signal the screen comes on and the sound level indicator LEDs light up. The higher
the sound level of the child's voice the larger the number of LEDs that light up. This function is useful when
the parents prefer to switch the speaker (18) off for peace and quiet.
Depending on which transmitter sends the signal the "Baby Unit 1" (19) or "Baby Unit 2" (20) indicator light
comes on.
4. The volume of the speaker (18) can be adjusted with the buttons (12) (13) ▲▼. On the screen the number of
bars indicating the volume also changes depending on the level chosen: the higher the number of bars, the
louder the volume of the speaker (18). When no bar is displayed and the icon
is cut completely.
5. If the receiver has been connected to function with 2 transmitters, Baby unit no. 1 always has priority. This means
that if the receiver is already in transmission with Baby unit no. 2 and Baby unit no. 1 starts to send, the
receiver then switches immediately to Baby unit no. 1 until the end of the transmission; it only resumes the
transmission with Baby unit no. 2 afterwards.
6. In order to prevent the parents from missing the signal from Baby unit no. 2 if it starts transmitting when the
receiver is already in transmission with Baby unit no. 1, the indicator light for Baby Unit 2 (20) flashes to warn
them. If the parents want to listen to the transmission of Baby unit no. 2 they can switch to the latter by briefly
pressing the "Menu" button (14). The "Baby Unit 2" indicator light (20) then lights up while the "Baby Unit 1"
indicator light (19) starts flashing (if the first child continues to cry). To switch back to Baby unit no. 1 it is enough
to press the "Menu" button (14) again. In this way it is possible to monitor two children at the same time.
7. In stand-by mode, if there are 2 transmitters the screen displays each transmitter's temperature and charge for
15 seconds alternatively. When one of the transmitters starts to transmit the receiver receives the transmission
immediately and displays the information concerning the transmitter in question until the signal comes to an end.
18
All manuals and user guides at all-guides.com
BABYPHONE PREMIUM CARE • Instruction manual
appears the speaker (18)
