Post Spool Installation Review:
Check the following:
Is the spool secured to the Element Feeder by the holder
•
cap, with the circular bar code facing in as shown in Section
7 B Step 9?
•
Is the wire fed onto the Element Feeder track, with the end
located just before the knife as shown in Section 7 B Step
16?
Is the wire shield in place, with one row of wire resting
•
loosely on top of it and the paper between the shield and the
rollers?
•
Is there one row slack wire below the spool?
Is the end of the paper feed secured to the rewind hub as
•
shown in Section 7 B Step 14?
•
Is any excess wire removed from the Element Feeder? No
wire should be present past the knife as shown in Section 7
B Step 14.
Open the top cover. Is any excess wire present on the
•
Holder as shown in Section 7 A Step 18?
Add Elements Message:
The message "ADD ELEMENTS" will be displayed on the LCD when
the eWire detects it is low on elements. When this message appears,
the spool must be replaced.
There will be a length of wire remaining on the spool when this
message appears. This extra length is left to ensure the final books
bind properly. This wire is meant to be discarded with the empty spool.
Continuing to operate the eWire after this message has been
displayed will result in unhooked sheets and unbound books.
Note: Opening and closing the element door will remove this message.
It is recommended to replace the spool immediately when this message
appears to prevent a jam condition.
C.
Storing Supply Spools:
Supply spools should always be stored vertically. Flat storage may
result in twisted or tangled wires. Always handle partially empty spools
very carefully.
Use the flexible magnet strip to secure loose ends of wire whenever a
partially used spool is removed from the machine.
If spools are to be stored in their cartons, cartons must be stacked
vertically. Refer to markings on the side of the package.
Examples of Proper Spool Storage:
Example of improper spool storage:
Do not store the magnet strips on the inside of the element feeder
drawer when not in use, this can cause wire jams. Store the magnets
as shown below on the element feeder drawer or away from the
machine. When storying them on the element feeder, ensure that they
are completely on the flat face of the drawer and are not near the spool.
Example of improper magnet storage:
10
eWire VFX
GB
