2. Fold the handle by rotating it forward
Figure 30
1. Operating position
3. Insert the carriage bolt (with the bolt head toward the
inside) through the handle bracket and the upper hole
in the handle end. Ensure that the square edges of each
carriage bolt fits into the upper or lower square hole in
its related handle bracket
Figure 31
1. Handle knob
4. Loosely install the handle knobs and carriage bolts on
the handle brackets.
5. To unfold the handle, refer to
Unfolding the Handle (page
All manuals and user guides at all-guides.com
(Figure
30).
g036582
2. Folded position
(Figure
31).
g032865
2. Carriage bolt
2 Assembling and
4).
15
