Changing the side at which the door
is hinged
Information!
Risk of damage from condensation for side by side
appliances.
If a side by side appliance is set up together with a
second appliance (as a side by side combination),
the door must remain hinged on the same side as
when it was delivered.
1. Slide the appliance 2/3 of the way into the recess.
2. Unplug the mains plug.
3. Open the appliance door.
5
4
4
4. Lift the cover parts (4).
5. Loosen the screws (5).
!
Warning!
When the hinges are folded together, there is a risk
of injury. Leave the hinges open.
6. Slide the appliance door outwards, unhinge it and
place it to one side.
7. Unscrew the screws (5) at the top and bottom, and
screw them in on the opposite side. The screws are
self tapping. Use a rechargeable power screwdriver.
34
All manuals and user guides at all-guides.com
5
8. Unscrew the screws (9) at the top and bottom.
9. Remove the hinges and screw them in on the
4
10. Close mounting holes that have opened up using
11. Hang the appliance door on the pre mounted
12. Tighten the screws (5).
13. Fit the cover parts (4).
10
10
opposite side with screws (9).
plugs (10).
screws.
9
9
