longer period of time or is not used
and maintained properly.
• Cutting injuries
WARNING! Danger due to elec-
tromagnetic field generated while the
tool is in operation. Under certain cir-
cumstances, this field may negat-
ively affect active or passive med-
ical implants. In order to reduce the
danger of serious or fatal injuries, we
recommend that individuals who wear
medical implants should consult their
doctor and the manufacturer of the
implant before operating the tool.
Preparation
WARNING! Risk of injury due to
unintentional start-up. Only insert
the battery into the device once the
device is fully prepared for use.
Control elements
Familiarise yourself with the operating
elements before using the device for
the first time.
• Switch lock (1)
• Locks the on/off switch against
unintentional operation.
• Unlocking: Press
• On/Off switch (2)
• Switching on: Press
• Switching off: Release
• Pendulum stroke switch (13)
Set pendulum movement of the
saw blade in 4 positions:
• 0 - no pendulum motion
• 1 - small pendulum motion
• 2 - medium pendulum motion
• 3 - large pendulum motion
12
• Switch (dust blower function)
(10)
Blower function for chip-free cut-
ting line
⭠
disable
Attaching and removing the
slide shoe
When working on scratch-sensitive
workpieces, working with the slide
shoe (9) is recommended.
Assembling the slide shoe (Fig. A)
1. Place the slide shoe (9) on the
front of the footplate (12).
2. Press the notches (8) on the back
of the slide shoe over the footplate
(12).
Disassembling the slide shoe
(Fig. A)
1. Press the slide shoe (9) on the
notches (8) away from the foot-
plate (12).
2. Pull the slide shoe (9) forward,
away from the footplate (12) and
off.
Attaching and removing the
saw blade
CAUTION! Risk of injury
when touching the saw blade.
Wear protective gloves when
handling the saw blade.
Requirements
• The saw blade has a T-shank
mount (single lug shank) like the
supplied saw blades (16/17/18).
• The saw blade is suitable for the
respective material.The scope of
delivery for the device includes
large-toothed saw blades for wood
⭢
enable
