and a fine-toothed saw blade for
metal and plastic.
• The chuck is free of splinters or
other material residue.
Installing the saw blade (Fig. B)
1. Turn the release of the chuck (23)
as far as possible. Keep the re-
lease of the chuck fixed in this po-
sition.
2. Place the saw blade (16/17/18)
into the chuck (14).When insert-
ing the saw blade, make sure that
the back of the saw blade is in the
notch of the guide roller (15).
3. Release the release of the chuck
(23) los.
4. Make sure that the saw blade (16/
17/18) is attached correctly and
the teeth are pointing in the cutting
direction.
Removing the saw blade (Fig. B)
Hold the device in a way that no per-
sons in the vicinity are injured by the
ejected saw blade.
1. Hold the saw blade (16/17/18)
firmly.
2. Turn the release of the chuck (23)
as far as possible.
The saw blade (16/17/18) is ejec-
ted.
If the saw blade is not ejected:
Hold the release of the chuck and
pull the saw blade from the chuck.
3. Release the release of the chuck
(23) los.
Using the parallel guide
The parallel guide can be fitted on
both sides of the tool.
Fitting the parallel guide (Fig. C)
1. Loosen the retaining screws (20) if
necessary.
2. Push the parallel guide (28) into
the holders (19).
3. Retighten the retaining screws
(20).
Removing the parallel guide (Fig. C)
1. Loosen the retaining screws (20).
2. Pull the parallel guide (28) out of
the holders (19).
Adjusting the parallel guide (Fig. C)
1. Loosen the retaining screws (20).
2. Set the scale on the parallel guide
(28) so that you can read the de-
sired cutting width on the footplate
(12) marking.
3. Retighten the retaining screws
(20).
4. Make a test cut, check the cutting
width and correct the position of
the parallel guide (28) if necessary.
Bevel cutting
Notes
• You can set the following cutting
angles:
−45°; −22.5°; 0°; 15°; 30°; 45°
Tools required
• Hex key (27)
Procedure (Fig. D)
1. Switch off the device and remove
the battery. Make sure that all
moving parts have come to a com-
plete stop.
2. Remove the splinter guard (25).
3. Loosen the hexagon socket
screws (11) with the hex key (27).
4. Pull the footplate (12) backwards
slightly.
5. Adjust the footplate (12) to the de-
sired position.
6. Press the footplate (12) forwards
into one of the notches.
7. Tighten the hexagon socket
screws (11) with the hex key (27).
