examined. It is possible that during this
some short signal tones may sound.
These are however without any mean-
ing, so long as no intensity display
13
appears in the detector display.
If there is an object, for which the search
is activated, in the vicinity of the detector,
several bars appear at first on the intensity
display
. As proximity to the search
13
object increases, the number of bars in-
creases on the intensity display (Fig. C).
If the detector is exactly over the search
object, a continuous signal tone sounds.
In the case of a search for a power line,
the voltage sign ( )
also appears in
11
addition to the intensity display.
Please use the pencil
for marking the
5
positions.
Always guide the detector in a straight
line in all the searches. To locate the ob-
ject more precisely, guide the detector
over the surface to be examined in a
forward direction for both Metal and
Wooden beam search (Fig. B). For the
Void search, the detector can be guided
in both forward and backward directions
(Fig. B). For the AC search, the detector
can be guided in all the four directions
(Fig. B).
The PUSH button
can be released
6
once the search is completed.
Integrated Pencil:
A pencil
has been included together
5
with the delivery content. Included pencil
can be stored inside the product by
5
inserting the pencil
on the pencil hole,
5
which is located on the right side of the
product. Make sure to insert the pencil
16 GB/IE/NI
