ACCESS TO MENUS Fig. 1
para . 1
para . 2
para . . . .
logic. 1
logic. 2
logic. . . .
hidden button
hidden button
PRG.
+/-
OK
1 A 9 C
PRG
DIAGNOSTICS
CODE
OK
ITA
- +
STRE
FRA
OK
stop
- +
phot
DEU
OK
- +
ENG
bar2
OK
- +
esp
OK
open
bft . . .
OK
+/-
Er01
0000
OK
+/-
Er02
Er05
00
OK
Er1x*
+/-
er3x*
Er4x*
Er5x*
ER61
ErFx*
Fig.2
F
F
E
C
D
See PARAMETERS
MENU
See LOGIC
MENU
release
desired button
release
desired button
See RADIO
MENU
2 2 F D
OK
0 1
OK
DIAGNOSTICS and WARNINGS
DESCRIPTION
pedestrian input activated
ped
START input activated
STOP input activated
attivazione ingresso PHOT
SAFETY EDGE input activated
bar
SAFETY EDGE input activated on slave motor
(opposite leaves connection)
CLOSE input activated
cls
OPEN input activated
opening limit switch input activated
svo
closing limit switch input activated
svc
the board is standing by to perform a com-
plete opening-closing cycle uninterrupted by
intermediate stops in order to acquire the tor-
set
que required for movement.
WARNING! Obstacle detection function is
not active
photocell test error
safety edge test error
safety edge test error on slave motor (opposite
leaves connection)
board hardware test error
reverse due to obstacle
thermal cutout error
anomaly in communication w/ remote devices check Scs1 serial connections
running off battery
limit switch error
Closing
B
ok 01
ok 01
check photocell connection and/or
logic settings
check safety edge connection and/or
logic settings
check safety edge connection and/or
parameter/logic settings
check connections to motor
check for obstacles in path
Allow motor to cool
--
check limit switch connections
* X = 0,1,...,9,A,B,C,D,E,F
35. 4 0
Set torque threshold
Maximum instantaneous motor torque
Scroll up
Scroll down
Con rm/Switch on display
Exit Menù
