1) Operation and assembly work may only be carried out by persons who are 18 years of age.
2.3
Intended use
The KESSEL backwater lifting station is designed for pumping faecal-free or faecal wastewater. The assemblies for the
pumps, the level measurement and the motor-driven backwater flap or two mechanical hinged flaps are installed in the drain
body.
In normal operation, the wastewater passes through the backwater lifting station to the wastewater sewer without backflow.
If the wastewater from the sewer system backs up into the backwater lifting station, the backwater is detected by an optical
probe (backwater flap). The motor-driven backwater flap closes. The wastewater from the building then collects in the drain
body of the backwater lifting station. The two hinged flaps close mechanically in the SWA version.
The switching signals of the level measurement in the tank are processed electronically in the control unit. An optical probe
(pump) can be used as a level detection option for the immersion pipe alarm. Once the relevant level has been reached,
pumping away via the drain body of the backwater lifting station is activated, against the backwater.
In the event of a power outage, the functional reliability of the motor-driven backwater flap can be guaranteed for approx.
2 hours. After this period, the backwater flap is closed to protect the building. The pumping of wastewater remains inactive
during a power outage.
Matrix
Ecolift L with an on-site pressure pipe
according to approval Z-53.2-493
Non-subordinate usage
Ecolift L with an integrated pressure
pipe
Use in line with the building regulations
Secondary usage
2.4
Product description
The system is the alternative to a sewage lifting station for faecal-free and faecal wastewater.
Drainage during the backwater phase takes place via a pressure pipe that can be connected above the backwater level
including a backflow preventer and shut-off valve for the pressure pipe.
The system does has a closure system for the polymer drainage pipe for safe closure of the drainage pipe in the event of
backwater. It consists of a hinged flap including an emergency closure, for manual locking if required, and an electrically
powered closure mechanism including a probe protected against wire breakage for the detection of backwater.
Other features include:
Bottom section made of LLD-PE
For installation in an exposed drainage pipe
Drainage via the sloped pipe to the sewer
Lifting function with 1 or 2 pumps
Backwater flap that can be closed by a motor, with 1 or 2 additional hinged flaps depending on the version, only active in
the event of backwater
Pipe penetration seals DN 70 for the on-site aeration and ventilation pipe
Depending on the version, control unit(s) with an integrated self-diagnostic system (SDS), display of the operating states
and integrated battery back-up for alarm signals
User-friendly menu guidance in a multi-line display
Self-diagnostic system (SDS) and reminder when maintenance is due
016-319
Approved activities on KESSEL systems
Visual check, inspec-
tion, change of battery
Emptying, cleaning
(inside), functional
check, configuration
of the control unit
SWA
Rainwater, grey water or wastewater
downstream of a light liquid separator
Rainwater, grey water or wastewater
downstream of a light liquid separator
Installation and operating instructions
Installation, replace-
ment, maintenance
of components,
commissioning
Work on electri-
cal installation
FKA
Black water or wastewater down-
stream of a grease separator
Black water or wastewater down-
stream of a grease separator
