3. The unit should be located on a firm & level foundation at
GB
normal counter top height.
4. There must be at least 200mm clearance around the ap-
pliance and 40mm clearance from the top to keep good air
ventilation.
5. Do not put anything on the top of the ice maker.
6. Allow 4 hours for the refrigerant fluid to settle before plug-
ging the ice maker in if the unit maybe fall upside down dur-
ing shipping or transportation.
• Place electrical and water supplies and drain fixtures in the
recommended locations as shown. (Fig.4 on page 4)
• Choose a well-ventilated area with temperatures above 10˚C
and below 32˚C. This unit MUST be installed in an area pro-
tected from the elements, such as wind, rain, water spray or
drips.
• The ice maker requires a continuous water supply with pres-
sure 1-8 Bar as required in above specification table. The
temperature of the water feeding into the ice maker should
be between 5˚C and 25˚C for proper operation.
Attention: Only use drinking water to make ice.
Connection to the water supply
(Fig.5 on page 4)
Attention: Be sure to use the new hose-sets supplied with the
appliance.
Connect the water supplying hose to the unit
1. First remove the clipper on the water inlet port (indicated
"B" in Fig.5 on page 4) located at the back of the unit. Press
inward the active out circle, then remove the anti-dusty
plug.
2. Insert the one end of the white water hose into the water
inlet port, and push inward completely, and install back the
clipper, then water hose connection is completed.
Connecting the water drain pipe
Pull out the water drainage cap with black color (indicated "A"
in Fig.5 on page 4), then connect the white drainage pipe in-
cluded in accessory, connect the other end of this drainage to
the main water drainage pipeline.
Connect the water hose to the water faucet of
the water main supply system
The supplied water quick-connector must be screwed to a fau-
cet; remove the clipper from the water quick-connector, insert
the other end of the water hose into this quick-connector port
completely, install back the clipper.
Important: The water pressure of main water supply system
must be 0.04-05 MPa at.
(Fig.6 on page 5)
1. Qucik-connector and the water faucet
2. Screw the qucik-connector on the water faucrt by the screw
thread, and remove the clipper
3. Insert the water hose completely
4. Insert back the clipper
Operating instructions
1. After all of the water pipe connecting is completed, plug in
the main power supply. Then press "On/Off" button on the
control panel to begin the ice making cycle, and the"Ice"light
12
will be on at same time. The digit window will display the
ambient temperature normally. The compressor, fan motor
and water pump will run during ice making process.
2. Each ice making cycle will last about 11 to 30 minutes, de-
pending on the ambient temperature and the water tem-
perature.
3. When the ice-making process is over the machine will
switch to ice-harvest process. At same time the system
will detect the water level, if the water level is lower than
required, "Add water"light starts flashing, open the water
inlet valve to supply extra water to water tank, when the
water supplying process is finished, the "Add water" light
is off again.
4. When the "Full " indicator is on, the unit stops running. If
you remove enough cubes, the unit will start to work again
after a 3 minute period.
5. During the ice-making process, press the "Increase and
Decrease" button to adjust the ice-making process duration
period length, this will change the thickness of the ice cube.
The default setting is zero, 1 minute will add or decrease to
the process per pressing of the "Increase and Decrease"
button. 5 seconds after the last press, the new setting are
programmed.
6. Bad water quality will cause bad quality of ice cubes and will
reduce the transparency of the ice cube.
NOTE: Created ice cubes are joined together and still need to
be broken apart.
Automatic self-cleaning program
• Start the self-cleaning program: After connecting all of the
water pipe, plug on the main power supply plug press the
"Timer / Clean" button for more than 5 seconds, this starts
the cleaning program. The "Clean" light will be on during
cleaning, the digit window will indicate the left time. The
self-cleaning program takes 30 minutes.
• Cancel the self-cleaning program: It takes about 30 minutes
to complete one self-cleaning program. When the program
is over, the system will be in off-state automatically. And also
you can press the "On / Off" button on control panel to cancel
the self-cleaning program by force.
Timer Setting
How to set the timer: When the machine is off, press the "Tim-
er/Clean" button to set the time when the machine has to turn
on. The "Timer" light will go on, the number in digital window
will flash to display in how many hours the machine will go on.
During the number flashing, press "Increase and Decrease"
button to add or remove hours, the default setting is zero. Five
seconds after setting, your desired setting will be programmed.
How to cancel the ON-Timer: Press the "Timer / Clean" button,
the number in digital window will flash to display the present
delay time of your ON-Timer, and press the button again to can-
cel the setting. Pressing the "On / Off" button will also cancel
the timer.
How to cancel the OFF-Timer: This is the same procedure as
for canceling the ON-Timer.
Normal Sounds
Your new ice maker may make sounds that are not familiar to
you. Most of the new sounds are normal. Hard surfaces like
