1
Dust cap
2
On-tool charge connector
3
Deadman's handle
4
Tool temperature indicator
5
Maximum force indicator
6
Light switch for LEDs
7
Battery pack fitting / adapter fitting
8
Carrying handle
9
LEDs
10 Battery pack
11 Battery temperature indicator
3.4
User interface of the tool
/i
1. on/off switch for
LEDs in carrying
handle.
2. Maximum force
reached when green.
3. Temperature of the
tool.
3.5
Technical specifications
/i
Description
max. working pressure
hydraulic oil type
vibration level
protection rate of the tool
sound emission @1m/3.25ft
sound emission @4m/13ft
temperature range
directives
1. The tool and battery pack can be put fully into in fresh water at
a maximum depth of 1 meter for 30 minutes.
/i
Description
retracted length
PTR50
User interface
Color Condition
Unit
(bar/MPa)
psi
-
m/s²
-
dB(A)
dB(A)
°C
°F
-
2006/42/EC, 2014/30/EU
Unit
mm
in
916.400.095_003
12 On/off switch
13 State Of Charge (SOC) indicator (see section 3.6.2)
14 Battery pack lock
15 Grip head (base side)
16 Cylinder
17 Plunger
18 Battery for laser pointer
19 Grip head with laser pointer (plunger side)
20 Light switch for laser pointer
21 Laser beam
Color: red, flashing
The tool is too hot.
Color: red
The tool is almost too
hot.
Color: green
The temperature is ok.
General
540 / 54
7832
ISO-L HV VG 36
< 2,5
1
IP57
73
64
-20 + 55
-4 + 131
PTR50
578
22.8
Action / Solution
Stop the tool.
Cool down the tool.
Slow down the operation.
Normal operation
including TRE03
1017
40.1
EN
39
