Hold the deadman's handle in this position to retract / close the tool.
5.7
Operating the light switch
On the tool is a light switch for the integrated LED lights.
•
Push the light switch to stop or start the LED lights.
NOTICE
When the tool starts, the LEDs come on by default.
5.8
Operating the laser pointer
5.8.1
Push the light switch
On the grip head is a switch for the laser pointer. Refer to Fig. 2, 20.
•
Push the light switch to start the laser pointer.
•
Push the light switch again to stop the laser pointer.
5.8.2
Replace the battery for the laser pointer
When the laser pointer does not operate when the switch is pushed, replace the battery for the laser
pointer. Refer to Fig. 9.
•
Remove the screw (B).
•
Remove the grip head.
•
Replace the battery in the battery holder (A)
NOTICE
Battery type: CR1/3N 3V 170 mAh lithium battery
5.9
Cam and groove connection system
Refer to Fig. 8.
The cam and groove lock the extension piece in position.
5.9.1
To attach
•
Push the accessory firmly on to the ram (C) until the cam (B) clicks in the groove.
5.9.2
To remove
•
Push the knob of the cam (B) to remove the accessory from the ram.
46
916.400.095_003
PTR50
