6 | Remote control
a
The units are connected with an Ether-
net cable.
a
Both units are switched on and ready
for use.
1. Press the button (Pos. 1) Setting
[
Figure 16
2. Press the button (Pos. 2) Cooking sys-
tem [
Figure
3. Press the button (Pos. 1) Remote con-
trol [
Figure
>
The remote control menu is open.
You can carry out the configura-
tion.
4. Click the button (Pos. 2) Unit name
[
Figure 17
>
Enter a unique unit name.
5. Click the button (Pos. 3) Unit colour
[
Figure
17].
>
Select the unit colour.
6. Switch the remote control button to
(Pos. 4) ON [
7. Press the button (Pos. 5) IP address of
unit to be controlled remotely
[
Figure
17].
>
Enter the IP address of the iCombi
to be controlled remotely.
>>
The units are connected together.
Important: You can switch between the
units (Pos. 6) [
Figure
When the controlling unit accesses the
unit to be controlled, the display is framed
in the selected colour (see step 5). This
shows that settings are now being carried
out on another unit.
80.51.370_iCombiPro-iCombiClassic_CD-E_IM_EU-west
].
16].
17].
].
Figure
17].
17].
NOTICE
Network connection for Combi-Duo
configuration with active remote
control
For units with active remote control,
the LAN ports are occupied and the
WiFi connection is deactivated. To
connect the units to a network, an
external switch must be set up.
Please note that the switch enables the
remotely controlled units to
communicate with each other and with
the network, e.g. for
ConnectedCooking.
Read through the ConnectedCooking doc-
umentation on networking for detailed in-
formation on configuration with active re-
mote control:
English
