sound. These are however without any meaning,
so long as no intensity display
the detector display.
If there is an object, for which the search is acti-
vated, in the vicinity of the detector, several bars
appear at first on the intensity display
proximity to the search object increases, the
number of bars increases on the intensity display
(Fig. C).
If the detector is exactly over the search object,
a continuous signal tone sounds.
In the case of a search for a power line, the
voltage sign ( )
to the intensity display.
Please use the pencil
Always guide the detector in a straight line in all the
searches. To locate the object more precisely,
guide the detector over the surface to be exam-
ined in a forward direction for both Metal and
Wooden beam search (Fig. B). For the Void search,
the detector can be guided in both forward and
backward directions (Fig. B). For the AC search,
the detector can be guided in all the four direc-
tions (Fig. B).
The PUSH button
search is completed.
Integrated Pencil:
A pencil
has been included together with the
5
delivery content. Included pencil
inside the product by inserting the pencil
the pencil hole, which is located on the right side
of the product. Make sure to insert the pencil
into the intended slot of the pencil hole on the
product. When necessary, the pencil
taken out from the pencil hole.
If one (or) a few more bars appear on the display
whilst slow scanning repeatedly at a particular
location of a wall, there could be an object, for
13
also appears in addition
11
for marking the positions.
5
can be released once the
6
appears in
. As
13
can be stored
5
5
can be
5
GB/IE/NI
15
