REPLACEMENT PARTS
ITEM
PART
QUANTITY
DESCRIPTION
NUMBER
NUMBER
REQUIRED
1
655126-96
Cartridge set, F2B2-RC2
1
4004603
Filter head, model F2000-B2B
1
2
4004605
Filter head, model F2000-B2M
1
3
4003596
Installation kit 2 & 3 stage
1
4
244960*
Faucet
1
5
4003530
Cover, 2 stage
1
6
4003641-EMEA
Cartridge timer without battery
1
*Image may be different than actual faucet
5
5
6
6
2
2
1
1
For replacement parts, contact your nearest Pentair distributor.
8 • F2000-B2B, F2000-B2M Filtration systems instruction manual
4
4
3
3
All manuals and user guides at all-guides.com
PERFORMANCE DATA
Important notice: read performance data and compare the
capabilities of the system with your actual water treatment
requirements. It is recommended that the supply water be tested,
before installing a water treatment system, to determine your water
treatment needs.
Test conditions
Flow rate
F2000-B2B
F2000-B2M
Filter capacity
F2000-B2B
F2000-B2M
Inlet pressure
Temperature
Testing was performed under standard laboratory conditions, actual
performance may vary,
Operating requirements for F2000-B2B and F2000-B2M systems:
Pressure
Temperature
CARTRIDGE SEQUENCE
F2000-B2B
F2000-B2B, F2000-B2M SYSTEMS
INSTALLED WITH F2B2-RC FILTER
CARTRIDGE SET
This system has been tested according to NSF/ANSI 42 and 53 for
reduction of the substances listed below. The concentration of the
indicated substances in water entering the system was reduced to
a concentration less than or equal to the permissible limit for water
exiting the system, as specified in NSF/ANSI 42 and 53.
= 2,27 Lpm
Conforms to NSF/ANSI 53 for VOC reduction. See performance data
= 2,27 Lpm
sheet for individual contaminant and reduction performance.
Model F2000-B2B, F2000-B2M systems
= 2'555 L
= 2'555 L
Influent challenge
Substance
= 4,1 bar
concentration
= 20°C+/- 2,5°C
Standard 42
Chlorine
2,0 mg/L±10%
taste & odor
Particulates
at least 10'000
(0.5-<1uM)
particulates/mL
class 1*
Standard 53
Cysts **
minimum 50'000/L
= 2,75-6,89 bar
Atrazine
0,009 mg/L ± 10%
= 4,4–37,8°C
Lead (pH
0,15 mg/L ± 10%
6.5)
Lead (pH
0,15 mg/L ± 10%
8.5)
Lindane
0,002 mg/L ± 10%
Chloroform
(VOC
0,300mg/L ± 10%
F2000-B2M
surrogate
chemical)
Flow rate = 2,2 Lpm; capacity = 2'555 L or 12 months
Testing was performed under standard laboratory conditions, actual
performance may vary.
* Reduces particles as small as 0,5-1 micron in size by mechanical
means
** NSF/ANSI Standard 53 certified to reduce cysts such as
Cryptosporidium and Giardia by mechanical means.
The Model F2000-B2B and F2000-B2M are tested and certified by
NSF International against NSF/ANSI Standard 42 and 53 for the
reduction of substances specified on the performance data sheet.
EPA Est. 082989-CHN-001
F2000-B2B, F2000-B2M Filtration systems instruction manual • 9
Max. permissible
Reduction
Minimum
Average
product water
requirements
reduction
reduction
concentration
≥50%
95,9%
>85%
97,9%
99,95%
99,97%
99,99%
0,003 mg/L
90,5%
93,7%
0,010 mg/L
99,3%
99,9%
0,010 mg/L
99,3%
99,6%
0,0002 mg/L
94,8%
97,4%
96,5%
98,8%
