7. PRODUCT USE / OPERATION
7.1 BEFORE USE: ACTIVATION &
REGISTRATION
To make the charge point ready for use the owner needs
to activate the charge point through our online portal
my.newmotion.com. The serial number of the charge point
is required for this process and can be found on the right
hand side of the charge point.
Charge cards can be activated in the same online portal.
7.2 REGULAR USE
First step is to connect your car to the charge point by
plugging in the charge cable.
If you are using Plug&Charge the session will start
automatically.
If you have to identify first; swipe your charge card above
the LED.
First the LED will flash green to authenticate the card,
after authentication, the session will start. If the LED
flashes red, the session is not accepted.
When the car has delayed charging configured, the LED
will remain green, until charging can start from car and
charge point.
Start charging? Plug in & identify
Stop charging? Identify & unplug
Full or waiting to charge
Plug in or identify
Charging
Not accepted
Error
Flashing green or multi colors: rebooting procedure
or software update procedure for charge point.
INSTALLATIEHANDLEIDING – P19
MANUEL D'INSTALLATION – P19 | P19
All manuals and user guides at all-guides.com
VERSION 0129NM02INT01
7.3 TETHERED CABLE
If you have purchased a charge point with tethered cable
functionality, this chapter will explain how to properly store
the tethered cable at the end of a charge session. After
the charge session is complete and the car has unlocked
the tethered cable, you roll the cable around the back of
charge point and connect the connector into the dummy
socket of the charge point. Make sure to fit the tethered
cable into the designed notch on the backside of the
charge point for optimal storage. Also, please be sure to
always hang the connector back into the dummy socket of
the charge point, so that the connector is protected against
water and dirt.
