MONOSPLIT INSTALLATION
Note: refer to wiring diagrams at the end of the manual
3. Fasten the cables using the cable clamp.
4. Put the cover back in place, ensuring it is positioned correctly.
3.3 Connecting to the mains electricity supply
Appliance connection must adhere to European and national standards, and must be protected by a 30 mA differential
switch. Connection to the mains must be permanent (not using a plug) and equipped with an omnipolar switch com-
plying with current CEIEN standards (contact air gap of at least 3 mm when open, preferably fitted with a fuse). Proper
connection to an efficient earthing system is essential for ensuring safe operation of the device.
1. Remove the cover.
2. Connect the conductors to the screw terminals. Screw the terminal board screws tightly to avoid any loosening.
3. Fasten the cables using the cable clamp.
4. Put the cover back in place, ensuring it is positioned correctly.
MONOSPLIT INSTALLATION
W
Note: refer to wiring diagrams at the end of the manual
3.4 Connection types
MONOSPLIT INSTALLATION
External unit model
PRIOS R32
C
25 MD0-O
PRIOS R32 CC35 MD0-O
PRIOS R32 50 MD0-O
PRIOS R32 70 MD0-O
MULTISPLIT INSTALLATION
External unit model
Power supply
DUAL 50 XD0C-O
220-240 ~ 50 Hz
TRIAL 80 XD0C-O
220-240 ~ 50 Hz
QUAD 110 XD0C-O
220-240 ~ 50 Hz
54 /
1L 2N S
L N
W
1L 2N S
L N
Power supply
Power supply
Switch type
220-240 ~ 50 Hz
20A
220-240 ~ 50 Hz
20A
220-240 ~ 50 Hz
20A
220-240 ~ 50 Hz
30A
Switch type
20A
30A
30A
MULTISPLIT INSTALLATION
MULTISPLIT INSTALLATION
Power
supply
Connection
Connection cable
cable type
5G, 1,5 mm
H07RN-F
2
5G, 1,5 mm
H07RN-F
2
5G, 2,5 mm
H07RN-F
2
5G, 2,5 mm
H07RN-F
2
Connection
Connection cable
cable type
4G 1,5 mm
2
H07RN-F
4G 1,5 mm
H07RN-F
2
4G 1,5 mm
H07RN-F
2
L
N
L (A) N (A) S (A)
L (A) N (A) S (A)
L
N
Power supply
Power supply
cable
cable type
3G 1,5 mm²
H07RN-F
3G 1,5 mm²
H07RN-F
3G 2,5 mm²
H07RN-F
3G 2,5 mm²
H07RN-F
Power supply
Power supply
cable
cable type
3G 1,5 mm
2
H07RN-F
3G 1,5 mm
H07RN-F
2
3G 2,5 mm
H07RN-F
2
