Battery Type
The DCH481 operates on a 54‑volt battery pack.
These battery packs may be used: DCB546, DCB547, DCB548,
DCB549. Refer to Technical Data for more information.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual before use.
Wear ear protection.
Wear eye protection.
Visible radiation. Do not stare into light.
Date Code Position (Fig. D)
13
The production date code
by a 2‑digit week and is extended by a 2‑digit factory code.
Description (Fig. A)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury could result.
1
Battery pack
2
Battery release button
3
Side handle
4
Trigger switch
5
Mode selector dial
6
Mode selector release
button
Intended Use
Your cordless rotary hammer has been designed for
professional drilling and hammerdrilling applications, as well as
chipping applications.
DO nOT use under wet conditions or in the presence of
flammable liquids or gases.
Your cordless rotary hammer is a professional power tool.
DO nOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
this tool.
Young children and the infirm. This appliance is not
•
intended for use by young children or infirm persons
without supervision.
•
This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with this product.
Overload Clutch
In case of jamming of a drill bit, the drive to the drill spindle is
interrupted. Because of the resulting forces, always hold the
consists of a 4‑digit year followed
7
Main handle
8
Bit holder
9
Sleeve
10
Worklight
11
Anti‑rotation indicator
tool with both hands and take a firm stance. After the overload,
release and depress the trigger to re‑engage drive.
Mechanical Clutch
These tools are fitted with a mechanical clutch. The indication
that the clutch has activated will be an audible ratcheting
together with increased vibration.
Anti‑Rotation System (Fig. D)
In addition to the clutch, an anti‑rotation system offers increased
user comfort and safety through an on‑board, anti‑rotation
technology capable of detecting if the user loses control of
the hammer. When a jam is detected, the torque and speed are
reduced instantly. This feature prevents self rotation of the tool
reducing the occurrence of wrist injuries.
The anti‑rotation system indicator
indicate status.
Indicator
Diagnosis
OFF
Tool is functioning
normally
SOLID
Anti‑Rotation
System has
been activated
(ENGAGED)
Active Vibration Control
For best vibration control, hold the tool as described in Proper
Hand Position.
The active vibration control neutralises rebound vibration from
the hammer mechanism. Lowering hand and arm vibration,
it allows more comfortable use for longer periods of time and
extends the life of the unit.
The hammer only needs enough pressure to engage the active
vibration control. Applying too much pressure will not make
the tool drill or chip faster and active vibration control will
not engage.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
WARNING: Use only D
Inserting and Removing the Battery Pack
from the Tool (Fig. B)
nOTE: Make sure your battery pack
To Install the Battery Pack into the Tool
Handle
1
1. Align the battery pack
handle (Fig. B).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap into place.
EngLIsH
11
will illuminate to
solution
Follow all warnings and instructions
when operating the tool.
With the tool properly supported,
release trigger. The tool will
function normally when the trigger
is depressed again and the indicator
light will go out.
WALT battery packs and chargers.
e
1
is fully charged.
with the rails inside the tool's
