Mode – Ready and Rest
In order for the spa to heat, a pump needs to circulate water through the heater. The pump that performs this function
is known as the "heater pump."
The heater pump can be either a 2-Speed Pump 1 or a circulation pump.
If the heater pump is a 2-Speed Pump 1, READY Mode will circulate water periodically, using Pump 1 Low, in order
to maintain a constant water temperature, heat as needed, and refresh the temperature display. This is known as
"polling."
REST Mode will only allow heating during programmed filter cycles. Since polling does not occur, the temperature
display may not show a current temperature until the heater pump has been running for a minute or two.
Circulation Mode (See Page 4, under Pumps, for other circulation modes)
If the spa is configured for 24HR circulation, the heater pump generally runs continuously. Since the heater pump is
always running, the spa will maintain set temperature and heat as needed in Ready Mode, without polling.
In Rest Mode, the spa will only heat to set temperature during programmed filter times, even though the water is
being filtered constantly when in Circulation Mode.
Sub-Menu Detail – MODE – Ready and Rest
Main Screen
To next item in
Toggle between READY and REST
Main Menu
Pressing Light when the display is toggled will go to Main Screen.
If not toggled
READY Mode will allow the spa to Poll and determine a need for heat. The panel will maintain a "current" temperature display.
REST Mode will not Poll and will only heat during filter cycles. The panel will not display a current temperature at all times.
Main Screen
1 Hour
The Main Screen will display RUN PUMP FOR TEMP if the filtration pump has not run for over 1 hour.
The Main Screen will display normally during Filter Cycles or when the spa is in use.
If the filtration pump has been off for an hour or more, when any function button, EXCEPT Light, is pressed on the panel,
the pump used in conjuncton with the heater will run so that temperature can be sensed and displayed.
Ready-in-Rest Mode
READY/REST appears in the display if the spa is in Rest Mode and Jet 1 is pressed. It is assumed that the spa is
being used and will heat to set temperature. While Pump 1 High can be turned on and off, Pump 1 Low will run until
set temperature is reached, or 1 hour has passed. After 1 hour, the System will revert to Rest Mode. This mode can
Sub-Menu Detail – MODE – Ready-in-Rest
also be reset by entering the Mode Menu and changing the Mode.
Main Screen
Main Screen
J
Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370,6590188, 6976052, 6965815,
7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright
of Balboa Water Group.
While the Temperature is
still flashing, press Light
repeatedly until MODE
appears in the LCD.
Main Screen
To Set
*****
Waiting a few
seconds reverts to
original settings
Key
Indicates Flashing or Changing Segment
Indicates Alternating or Progressive Message - every 1/2 second
A temperature button, used for "Action"
Light or dedicated "Choose" button, depending on control panel configuration
Waiting time that keeps the last change to a menu item.
*****
Waiting time (depends on menu item) that reverts to original setting
and ignores any change to that menu item.
