Balboa TP600 Programmeerhandleiding pagina 45
Standaard menu's
Beschikbare talen
Beschikbare talen
General Messages
Priming Mode – M019
Each time the spa is powered up, it will enter Priming Mode. The purpose of Priming Mode is to allow the user to run
each pump and manually verify that the pumps are primed (air is purged) and water is flowing. This typically requires
observing the output of each pump separately, and is generally not possible in normal operation. Priming Mode lasts
4 minutes, but you can exit it earlier by pressing any Temp button. The heater is not allowed to run during Priming
Mode.
NOTE: If your spa has a Circ Pump, it will turn on with Jets 1 in Priming Mode. The Circ Pump will run by itself when
Priming Mode is exited.
or
Water Temperature is Unknown
After the pump has been running for 1 minute, the temperature will be displayed.
Too Cold - Freeze Protection
A potential freeze condition has been detected, or the Aux Freeze Switch has closed, and all pumps and blower are
-
activated. All pumps and blower are ON for at least 4 minutes after the potential freeze condition has ended, or when \
the aux freeze switch opens.
In some cases, pumps may turn on and off and the heater may operate during Freeze Protection.
This is an operational message, not an error indication.
Water is too Hot (OHS) – M029
One of the water temp sensors has detected spa water temp 110°F (43.3°C) and spa functions are disabled. System
will auto reset when the spa water temp is below 108°F (42.2°C). Check for extended pump operation or high
ambient temp.
Safety Trip - Pump Suction Blockage* – M033
The Safety Trip error message indicates that the vacuum switch has closed. This occurs when there has been a
suction problem or a possible entrapment situation avoided. (Note: not all spas have this feature.)
M0XX numbers are Message Codes. See Page 18.
* This message can be reset from the topside panel with any button press.
Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370,6590188, 6976052, 6965815,
7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright
of Balboa Water Group.
44
