Balboa TP600 Programmeerhandleiding pagina 34
Standaard menu's
Beschikbare talen
Beschikbare talen
Restricting Operation
The control can be restricted to prevent unwanted use or temperature adjustments.
Locking the panel prevents the controller from being used, but all automatic functions are still active.
Locking the Temperature allows Jets and other features to be used, but the Set Temperature and other programmed
settings cannot be adjusted.
Temperature Lock allows access to a reduced selection of menu items.
These include Set Temperature, FLIP, LOCK, UTIL, INFO and FALT LOG.
Sub-Menu Detail – Locking the Set Temperature or All Buttons
Main Screen
Locks Temp. and Settings.
To next item in
Main Menu
Panel Locked
Main Screen
Any
Button
Press
Temperature Locked
Main Screen
When the Temperature is locked, the panel will display the Set Temperature
by pressing a Temperature Button, as ususal.
LOCK will appear if an attempt to reset the temperature is made with a subsequent button press.
Adjustable settings in the menus are also locked.
Other function buttons will operate normally.
Unlocking
Sub-Menu Detail – Unlocking the Set Temperature or All Buttons
This Unlock sequence may be used from any screen that may be displayed on a restricted panel.
While pressing and holding the Temperature Button (or UP button, if available),
Slowly press and release the Light Button two times.
NOTE: If the panel has both an UP and a Down button, the ONLY button that will work in the Unlock Sequence is the
UP button.
Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370,6590188, 6976052, 6965815,
7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright
of Balboa Water Group.
While the Temperature is
still flashing, press Light
repeatedly until LOCK
appears in the LCD.
Locks all function buttons.
A few seconds
Main Screen
A Few
Seconds
Main Screen
A Few
Seconds
Key
Indicates Flashing or Changing Segment
Indicates Alternating or Progressive Message - every 1/2 second
A temperature button, used for "Action"
Light or dedicated "Choose" button, depending on control panel configuration
Waiting time that keeps the last change to a menu item.
*****
Waiting time (depends on menu item) that reverts to original setting
and ignores any change to that menu item.
*****
Waiting a few
seconds reverts
to origianl settings
LOCK will remain on the display
for 3 seconds and then revert to the normal display.
Main Screen
A Few
Seconds
Main Screen
To Set
33
08-06-09
