Balboa TP600 Programmeerhandleiding pagina 35
Standaard menu's
Beschikbare talen
Beschikbare talen
Hold (Standby)
Hold Mode – M037*
Hold Mode is used to disable the pumps during service functions like cleaning or replacing the filter. Hold Mode will
last for 1 hour unless the mode is exited manually.
Drain Mode
Some spas have a special feature that allows a pump to be
employed when draining the water.
When available, this feature is a component of Hold Mode.
Sub-Menu Detail – STANDBY FOR 1 HR
Main Screen
A few seconds
To next item in
Main Menu
OR
M037 is a Message Code. See Page 18.
Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370,6590188, 6976052, 6965815,
7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright
of Balboa Water Group.
While the Temperature is
still flashing, press Light
repeatedly until HOLD
appears in the LCD.
Main Screen
Press JET Button for Pump Out/Drain, only if Drain Mode is enabled.
Main Screen
or
a few seconds
Key
Indicates Flashing or Changing Segment
Indicates Alternating or Progressive Message - every 1/2 second
A temperature button, used for "Action"
Light or dedicated "Choose" button, depending on control panel configuration
Waiting time that keeps the last change to a menu item.
Waiting time (depends on menu item) that reverts to original setting
*****
and ignores any change to that menu item.
Some spas will allow
PUMP ING OUT (Drain Mode)
with Jet 1 button
Jet 1 will toggle pump on and off.
Indicates a Menu Item that
Depends on a Manufacturer
Configuration and
may or may not appear.
J
04-11-09
34
