Balboa TP600 Programmeerhandleiding pagina 33
Standaard menu's
Beschikbare talen
Beschikbare talen
Show and Set Time-of-Day
Be sure to set the Time-of-Day
Setting the time-of-day can be important for determining filtration times and other background features.When in the
TIME menu, SET TIME will flash on the display if no time-of-day is set in the memory.24-hour time display can be set
under the PREF menu. (See Page 12)
Sub-Menu Detail – Show and Set Time of Day
Main Screen
To next item in
Main Menu
Note:
If power is interrupted to the system, Time-of-Day is not stored. The system will still operate and all other user
settings will be stored. If filter cycles are required to run at a particular time of day, resetting the clock will return the
filter times to the actual programmed periods.
When the system starts up, it defaults to 12:00 Noon, so another way to get filter times back to normal is to start up
the spa at noon on any given day. SET TIME will still flash in the TIME Menu until the time is actually set, but since
the spa started at noon, the filter cycles will run as programmed.
Flip (Invert Display)
Sub-Menu Detail – FLIP (Invert Display)
Main Screen
Toggle the inversion of the segmented characters
To next item in
Pressing Light when the display is toggled will go to Main Screen.
Main Menu
If not toggled
Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370,6590188, 6976052, 6965815,
7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright
of Balboa Water Group.
While the Temperature is
still flashing, press Light
repeatedly until TIME
appears in the LCD.
Main Screen
A few seconds
If Time of Day is not actually programmed due to a power cycle,
SET TIME will appear in the menu instead of just TIME.
While the Temperature is
still flashing, press Light
repeatedly until FLIP
appears in the LCD.
Main Screen
or
a few seconds
Key
Indicates Flashing or Changing Segment
Indicates Alternating or Progressive Message - every 1/2 second
A temperature button, used for "Action"
Light or dedicated "Choose" button, depending on control panel configuration
Waiting time that keeps the last change to a menu item.
*****
Waiting time (depends on menu item) that reverts to original setting
and ignores any change to that menu item.
*****
Waiting a few
seconds reverts
to origianl settings
Note:
Some panels may have a dedicated FLIP button,
which allows the user to flip the display with a
single button-press.
Main Screen
To Set
32
