7.1. Device keys
The meaning of the device keys is shown below:
DEVICE KEYS AND FUNCTION (TABLE 5)
KEY
UP
DOWN
RIGHT
LEFT
OK
7.2. LEDs
The meaning of the device LEDs is shown below:
DEVICE LEDs AND DESCRIPTION (TABLE 6)
COLOUR
DESCRIPTION
Power supply Equipment
GREEN 1
Active alarm/s
RED
--
ORANGE
GREEN 2
System status
C/ Sir Alexander Fleming, 7 _ 46980 Paterna (Valencia) SPAIN info@tewis.com www.tewis.com (+34) 963 13 42 02
DESCRIPTION (PRESS AND RELEASE)
Increases a value Goes
to the next icon
Decreases a value
Goes to the next icon
Go to the next icon
Allows the entered data to be scrolled to the right.
Exit without saving the configuration
Return to the previous level
Allows the entered data to be scrolled to the left.
Accesses the menu if maintained held and confirms value / exit by
saving the configuration.
Moves to the next level (access to folder, subfolder, parameter, value)
ON
Equipment powered
Active alarm
--
System ON
OFF
Equipment not powered
No alarms active
--
System OFF
