Modify configuration: This function allows the Initial configuration, to be performed again, allowing the user to change previously
set values. Refer to the chapter 14.1 Initial configuration.
Once confirmed this choice, the device will stop and will restart from the initial configuration. To run the system
it is necessary to redo the configuration..
-
Initial configuration via DConnect App: this feature allows the initial configuration to be performed again via the Dconnect
application. Refer to the chapter 14.1.1 Initial configuration with DConnect App.
Once confirmed this choice, the device will stop and will restart from the initial configuration. To run the system
it is necessary to redo the configuration..
Communication protocol: This screen allows you to manage the Modbus communication protocol, for BMS to be applied to the
-
device. Specifically, it is possible to:
Configure the Modbus protocol (see chapter 17), if not done at first Installation;
•
Activate or deactivate the Modbus protocol;
•
Consult the details of the Modbus configuration in read-only mode.
•
Additional settings: This screen allows the activation or deactivation of the alarm buzzer that warns and accompanies any
-
warning and/or alarm phenomena occurring in the system.
System
System settings
Below are the main system settings.
Select language
Screen brightness
Connectivity details
ENGLISH
The screen shows the parameters identifying the panel and its firmware versions on the
right, and a QR-code containing more product identification data on the left.
When you access this menu page, you can view the functions described in the System
settings section.
ATTENTION!!
Press and hold the key
complete with all product identification data. To exit this page, wait 2
minutes or press any key.
Measuring system
Screen off
Press and hold the key
59
for 5 seconds to display the QR-code
to display the complete connectivity serial
