Removing the sanding plate
(Fig. B)
1. Open the clamping lever (30).
2. Pull the sanding plate (27/29/31) first
forwards, then downwards.
3. Mount a sanding plate.
Mounting the sanding plate
(Fig. B)
1. Open the clamping lever (30).
2. Slide the sanding plate (27/29/31)
first from below, then backwards onto
the delta sanding disc (26).
3. Close and lock the clamping lever
(30).
Removing, emptying and
fitting the dust collection
box removing
Removing the dust collection box
1. Grasp the dust collection box (5) by
the filter holder (22).
2. Unlocking the dust collection box: Turn
the dust collection box (5) so that the
marking on the dust collection box
points to ὑ.
3. Pull off the dust collection box (5).
Opening and emptying the dust
collection box
1. Press the dust collection box (5) on the
filter cover (20) together and pull both
parts apart.
2. Pull the filter bag (21) from the filter
holder (22).
3. Empty the filter bag (21).
4. Pull the opening of the filter bag (21)
over the ring on the filter holder (22).
5. Close the dust collection box (5).
Make sure the filter bag fits correctly.
Fitting the dust collection box
1. Before connecting, ensure that the dust
collection box (5) is tightly closed.
14
2. Hold the dust collection box (5) at a
slight angle to slide it on. Push the dust
collection box onto the dust extraction
connection (17) as far as it will go. The
nose in the dust collection box must be
inserted into the groove (16) on the
connection.
3. Locking the dust collection box: Turn
the dust collection box (5) so that the
marking on the dust collection box
points to ὑ.
Connecting dust extraction
Notes
• Make sure that the vacuum cleaner is
suitable, e.g. workshop vacuum clean-
er. Normal household vacuum cleaners
are not suitable for vacuuming sanding
material. This information can be found
in the operating instructions of the ex-
ternal device.
Procedure
• Try connecting the external suction
hose (18) (not included) directly to the
dust extraction connection (17).
• If this does not succeed, insert the ad-
apter for dust extraction (19) into the
connection for dust extraction (17).
Connect the external suction hose (18)
to the adapter for dust extraction.
• Adapter for dust extraction (19) and
external suction hose (18) can be eas-
ily pulled off the connection for dust ex-
traction (17).
Checking the battery charge
level
LEDs
red, orange, green Battery charged
red, orange
red
Meaning
Battery partially
charged
Battery needs to be
charged
