1. Press the button (11) next to the
charge level indicator button (12) on
the battery (7).
The LEDs of the charge level indicator
show how much charge remains in the
battery.
2. Charge the battery (7) when only the
red LED on the charge level indicator
(12) is illuminated.
Charging the battery
See also the charger instruction manual.
Notes
• If warm, allow the battery to cool be-
fore charging.
• Do not expose the battery to direct sun-
light for long periods and do not place
it on a radiator (max. 50°C).
Charging the battery
1. Remove the battery (7) from the
device.
2. Push the battery (7) into the charging
slot of the battery charger (14).
3. Connect the battery charger (14) to a
power outlet.
4. After charging, disconnect the battery
charger (14) from the mains.
5. Pull the battery (7) out of the battery
charger (14).
Operation
Working instructions
• Do not use the device without a dust
collection box or external dust extrac-
tion. Use of dust extraction can reduce
hazards caused by dust. When us-
ing sanding sheets without ventilation
holes, dust extraction is not possible.
Make sure that the workplace is well
ventilated.
• Move the appliance against the work-
piece once it is switched on.
• After machining, lift the sanding disc up
before turning off the device.
• Only work with sanding sheets in per-
fect condition to achieve good sanding
results.
• Work with low and even pressure and
even forward pressure. This protects the
appliance and the sanding sheet.
• Do not use the same sanding sheet to
sand different materials (e.g. metal and
then wood).
• Empty the dust collection box or the va-
cuum cleaner regularly in order to en-
sure optimal suction power.
Inserting and removing the
battery
WARNING! Risk of injury due to
unintentional start-up. Only insert the re-
chargeable battery into the device once
the device is fully prepared for use.
NOTICE! Risk of damage! An incorrect
battery can damage the device and bat-
tery.
Inserting the battery
1. Push the battery (7) along the guide in-
to the battery holder (6).
You will hear the battery click into
place.
Removing the battery
1. Press and hold the battery release (13)
on the battery (7).
2. Pull the battery out of the battery hold-
er (6).
Switching on and off
Switching on
1. Use the rotary wheel (1) to select a
speed level (1 ... 6).
2. Move the On/Off switch (3) forward
to the "I" (ON) position.
3. Wait until the device has reached full
speed.
GB
IE
NI
15
