Install
Installation in the bathroom
CAUTION!
The device should not be mounted directly
above the connection box/wall socket.
CAUTION!
The power supply cable should not hang in
front of the air outlet
Please carry out all electrical connection and installa-
tion works in accordance with the relevant national and
regional regulations.
Hang the device onto the wall. The device's air outlet
should be at the bottom. Use the dowels
G
screws
included in the delivery.
I
B
Uninstall
A
.
G
J
Please note: Make sure that the wall can bear
weights of at least 4.1 kg.
CAUTION!
The ceramic wall fan heater should only
be used in the protection zone 3 of a bath-
room (see figure 7)!
Protection area 0 This is the area that is inside
Protection area 1 This area is limited in height
Protection area 2 This area is limited in height
Protection area 3 Safety zone 3 applies to
7
Protection area 0
Protection area 1
225cm
Protection area 0
Protection area 2
1. Drill two holes with a 6 mm drill and insert the sup-
plied wall dowels
2. Screw the fastening screws
. Each screw
J
PLEASE NOTE: When drilling, make sure that you
and
do not damage concealed power lines!
the bathtub or shower tray.
(225 cm) and extends to the
outer edges of the bathtub or
shower tray.
(225 cm) and extends to the
vertical surfaces at the limit
of zone 1 and its parallel
vertical surfaces extending
60 cm beyond the edge of
zone 1.
areas outside the three saf-
ety zones mentioned above.
Protection area 1
Protection area 2
60cm
225cm
200cm
**
Protection area 3
Protection zones
into them.
J
into the wall dowels
I
shall protrude to about 10 mm.
I
Protection area 3
45cm
GB/IE/NI
