ENGLISH
when transporting it in the future. In case the original packaging is disposed of, make
sure all packaging materials are recycled accordingly.
2.
Make sure all parts and components are included and in good conditions. If there is any
piece missing or in bad conditions, contact the official Cecotec Technical Support Service
immediately.
Box contents
•
ForceClima 9400 SoundLess Heating portable air conditioner
•
Window kit
•
Remote control
•
Instruction manual
3. PRODUCT INSTALLATION
NOTE:
•
Leave a minimum of 50 cm distance to walls and other objects. Fig. 6
•
Do not install and use the air conditioning in the bathroom or other humid environments.
•
Before using the portable air conditioner, keep it upright for at least two hours. When
moving the appliance from one place to another, always do it with the device in an
upright position and leaving it in a flat surface.
•
The air outlet pipe should be 28-150 cm long, this length is based on the specifications
of the air conditioner. Do not use extendible pipes or replace the pipe with a different
one, as this may cause the product to malfunction. The exhaust pipe must be clear of
obstructions; otherwise, it may cause overheating.
Installing of the air outlet pipe. Fig. 7
1.
Stretch the air outlet pipe.
2.
Insert the pipe into the air outlet.
3.
Turn the end counterclockwise to fix it to the air conditioner body.
NOTE:
•
The flat end of the exhaust pipe joints must be snapped into place.
•
The air outlet pipe must not be twisted or bent more than 45°. Keep the air outlet pipe
free of obstructions.
Installing the window sealing plate
You can install the window sealing plate either vertically (Fig. 8) or horizontally (Fig. 9). Adjust
the size of the opening so that the sealing plate remains fixed in it.
64
FORCECLIMA 9400 SOUNDLESS HEATING
The following checks must be applied to installations using flammable refrigerants:
•
The charge size is in accordance with the size of the room within which the refrigerant
containing parts are installed.
•
Ventilation machinery and outlets are properly operated and unobstructed.
•
If an indirect cooling circuit is used, the secondary circuit must be checked for the
presence of refrigerant.
•
Equipment marking remains visible and legible. Markings and symbols that are illegible
should be corrected.
•
The components or refrigerant piping are installed in a location where they are not
susceptible to exposure to any substance that may corrode the refrigerant containing
components, unless the components are constructed of materials that are inherently
corrosion resistant or are adequately protected against corrosion.
4. OPERATION
The following functions can be activated from the control panel or from the remote control.
On/Off
When the device is turned on, it will beep and enter standby mode. Touch the power iconto
turn the device on and off.
Mode
Press the mode icon to switch between cooling, fan, and dehumidification modes.
Note: when the appliance is running in cooling and dehumidification mode, the condensate
drainage will be done through the upper condensate outlet. When the device is running in
heating mode, the condensate drainage will be done through the lower condensate outlet.
Note: when changing from heating mode and vice versa, the appliance will take some time
to change from one mode to the other. It may take a few minutes for the appliance to start
running normally again.
Sleep mode
In cooling mode, press the increase and decrease icons to activate the Sleep mode. The
device will operate saving energy and silently.
Increase and decrease icons
Use these icons to increase or decrease temperature and time.
Temperature cannot be increased or decreased in fan or dehumidification mode.
ENGLISH
65
FORCECLIMA 9400 SOUNDLESS HEATING
