ENGLISH
Fan speed
Under the cooling mode, press the iconto select high or low wind speed operation.
This option is not available under the dehumidification mode.
NOTE:
Under certain conditions (defrost), it may not operate at the selected speed.
Timer
Press this iconto set the timer. When the timer symbol blinks, use the increase and decrease
icons to select the desired operating time.
The timer can be set from 1 to 24 hours, and the digits increase and decrease by 1 hour.
Drainage instructions
When the air conditioner stops operating because the water tank is full, turn it off and unplug
it from the power supply. The full tank indicator (FULL) will start blinking and the appliance
will not operate until the water inside the tank is drained.
Manual drainage. Fig. 10
1.
Place a container below the water outlet behind the body.
2.
Unscrew the drain cap and unplug the water plug. The water will automatically flow into
a container.
NOTE:
•
Move the device carefully, so as not to spill the water in the water tank at the bottom of
the body.
•
Keep the drain cap and the water plug properly.
•
During drainage, the body can be tilted slightly backwards.
•
If the water container cannot hold all the water, before the water container is full, stuff
the water outlet with the water plug as soon as possible to prevent water from flowing
to the floor or the carpet.
•
When the water is discharged, re-tighten the water plug and tighten the drain cap.
•
Restart the appliance after the plug and cap are installed, otherwise condensed water of
the appliance will flow to the floor or the carpet.
Continuous drainage. Fig. 11
1.
Unscrew the drain cap and unplug the water plug.
2.
Set the drainage pipe into the water outlet.
3.
Connect the drainage hose to a bucket or big container.
66
FORCECLIMA 9400 SOUNDLESS HEATING
Protection features:
Frost protection function
In cooling and dehumidification modes, if the temperature of the evaporator outlet pipe is
too low, the appliance will automatically enter protection mode to prevent damage to the
evaporator. The appliance will restart when the temperature is restored to normal values.
Condensate water flooding protection function
When the water level exceeds the maximum level allowed by the safety buoy, the appliance
will switch off and activate the FULL indicator on the control panel. To restart the device, the
water inside the device will need to be drained through the bottom drain plug (shown in detail
in the drainage instructions section). Once the water has been drained, the device will restart.
Automatic defrost
This air conditioner has an automatic defrost function.
Compressor protection function
To increase the service life of the compressor, it has a 3-minute delay booting protection
function after the compressor is turned off.
5. CLEANING AND MAINTENANCE
•
Turn off and unplug the device from the power supply before cleaning or repairing it.
•
Use a soft, dry (or slightly damp) cloth with some neutral cleaning agent to clean the
product's outside and prevent the accumulation of dust and dirt.
•
If the product is not going to be used for a long time, store it in a safe and well-
ventilated place.
•
Do not use detergent, scouring pads, chemically-treated cloths, petrol, benzene, alcohol,
thinner, or other solvents, as these can scratch and damage the tank and cause water leakage.
•
Do not immerse the product in water or other liquids.
Cleaning the filter. Fig. 12
•
If the filter is clogged with dust, the effectiveness of the air conditioning will be reduced.
Make sure to clean the filter once every two weeks.
•
Cleaning the upper filter frame
•
Unscrew the screw attached to the filter at the rear with a screwdriver and remove the filter.
•
Put the filter screen into warm water with neutral detergent (about 40 ºC / 104 ºC) and dry
it in the shade after rinsing clean. Make sure it is completely dry before reattaching it.
ENGLISH
67
FORCECLIMA 9400 SOUNDLESS HEATING
