the integrated
sensor.
The device may only be repaired by authorized specialists. Failure to do so
will void the warranty.
7. Accessories
Warnings and safety instructions
• Only use the accessories listed in this section. The use of other
components may damage the device or limit its functionality.
Part number
540-00192-00
540-00194-00
560-00198-00
540-00193-00
8. Technical data
Environmental
Item
Temperature
Relative humidity (non-
condensing)
Barometric
Dust and water resistance
Physical
Size
Weight
Screen
Plug connection
Power supply
Battery type
Battery duration
Recharge time
ECG
Electrode type
Lead set
Recording duration
Sampling frequency
Screen interval
Sampling speed
Bandwidth
inserted correctly.
Description
ECG cable with 2 electrodes, quick release fastener
USB charging cable, Micro D
ECG electrode, 10 pieces
External SpO2 sensor (optional)
Operating
5 to 45 °C
10 % to 95 %
700 to 1060 hPa
IP22
88×56×13 mm
64 g (Main unit)
2,4"-Touchscreen, Color, backlight
Micro D socket
Rechargeable lithium polymer battery
Daily measurements: > 200 times
Less than 2 hours on 90%
Integrated ECG electrodes
Lead I, Lead II
30 sec.
500 Hz / 16 Bit
1,25 mm/mV, 2,5 mm/mV, 5 mm/mV
10 mm/mV, 20 mm/mV
25 mm/s
0,67 to 40Hz
the correct position.
30
EN
Storage
-25 to 70 °C
10 % to 95 %
700 to 1060 hPa
