ENGLISH
(For machines without EcoFlex™ system)
3.
Fill the tank (21) with a solution suitable for the work to be performed.
Do not fill the tank completely, leave a few inches from the edge. Use the level hose (13) as reference.
Always follow the dilution instructions on the label of the chemical product used to prepare the solution.
The solution temperature must not exceed 40 °C.
(For machines with EcoFlex™ system)
Fill the tank (21) with clean water. Use the water removable filler hose (23).
4.
Do not fill the tank completely, leave a few inches from the edge. Use the level hose (13) as reference.
The water temperature must not exceed 40 °C.
Detergent tank filling (For machines with EcoFlex™ system)
5.
Lift the cover (34) and check that the recovery tank (33) is empty; if not, empty it using the drain hose (12).
6.
Close the cover (19).
7.
Grasp the handle (16) and carefully lift the tank (33).
8.
Fill the tank (25) with a detergent suitable for the work to be performed (highly concentrated detergent).
Do not fill the detergent tank completely, leave a few inches from the edge.
CAUTION!
Use only low-foam and non-flammable detergents, intended for automatic scrubber applications.
NOTE
To accelerate filling of the hoses and system operation (with a new system, if the system has been emptied for cleaning,
etc.), it is a good idea to drain the EcoFlex™ system once or several times (see the procedure in the Maintenance
chapter).
MACHINE START AND STOP
Starting the machine
1.
Prepare the machine as shown in the previous paragraph.
2.
To turn on the machine, insert the operator key (41) in its slot on the control panel (3); if the key is already inserted, press the
push-button (42).
In the first 2 seconds after machine start-up, the multifunction display (50) indicates the machine working hours (50-A) and the
3.
type of batteries installed (50-B).
NOTE
Check the battery charge level.
When the multifunction display shows at least one segment of the battery symbol (50-C) which is on but not flashing, the
machine is ready for use.
When the battery symbol (50-C) shows just one segment flashing, the batteries have to be charged (see the procedure in
Maintenance chapter).
4.
Drive the machine to the area it is required by starting it with your hands on the handlebar (1) and pushing the paddle (2)
forward to move forward, and backwards to move in reverse. The speed can be adjusted by pressing the paddle (2) more or
less. The maximum speed can be set with the push-buttons (45).
Stopping the machine
5.
Stop the machine by releasing the paddle (2).
6.
Turn off the machine by pressing push-button (42), or by removing the operator key (41) from the control panel (3).
NOTE
If the machine is on but not working, it automatically turns off after 5 minutes.
7.
Make sure that the machine cannot move independently.
CAUTION!
In the event of an emergency, to stop all machine functions immediately, disconnect the battery connector (9).
Reset the machine functions by connecting again the connector.
14
INSTRUCTIONS FOR USE
SC500 - 9099974000
revised 03/2016
11/2014
