Introduction
These operating - and installation instructions are part of the
product and contain all the information required to ensure cor-
rect and safe installation and use.
u
Read these instructions before installing and operating the
unit.
u
Keep these instructions ready to hand.
u
Hand these instructions on to the following owner or user
of the unit.
The table below describes the symbols that (may) be used on
the type label.
Symbol
Title/Meaning/
Referent
Read operator's
manual
ISO 7000 -
0790
Operator's
manual;
operating in-
structions
ISO 7000 -
1641
Service indic-
ator;
read technical
manual
ISO 7000 -
1659
1.1
Use of symbols and highlighting
DANGER
This signal word denotes a hazard with a high degree
of risk which, if not avoided, may lead to death or seri-
ous injury.
WARNING
This signal word denotes a hazard with a moderate
degree of risk which, if not avoided, may lead to minor
or moderate injury.
CAUTION
This signal word denotes a hazard with a low degree of
risk which, if not avoided, may lead to minor or moder-
ate injury.
NOTE
This symbol denotes a special technical feature or (if not
observed) potential damage to the product.
This symbol refers to separate documents which may be
enclosed or can be requested from Webasto.
ü Requirements for the following necessary action
1.2
Warranty and liability
The statutory warranty period applies. If the product is defect-
ive, please contact a Webasto service partner in your country.
You can find your nearest dealer at:
https://dealerlocator.webasto.com/en-int
Our experts will be happy to help you and will discuss the war-
ranty process with you in more detail.
9045225A_OI-II_Cool Top Trail 20G-24G ML
Function/description
To indicate that the operator's
manual or card should be read
before continuing the opera-
tion.
To identify information that
relates to the operating instruc-
tions. To indicate that the oper-
ating instructions should be
considered when operating the
device or control close to
where the symbol is placed.
To indicate that a machine or
equipment requires service. To
indicate that the technical
manual shall be consulted.
Webasto shall not assume liability for defects or damages that
are the result of disregarding the installation and operating in-
structions. This liability exclusion particularly applies to:
l Installation by untrained personnel.
l Improper use.
l Repairs not carried out by a Webasto service workshop.
l Use of non-genuine parts.
l Conversion of the unit without permission from Webasto.
l Mechanical damage to the equipment.
l Non-compliance with installation and operating instruc-
tions.
l Non-compliance with inspection and maintenance instruc-
tions.
l Operation with voltage levels other than specified in the
technical data.
l Damage to the remote control resulting from leaking bat-
teries.
l Damage resulting from contact with unsuitable substances,
such as chemical products and unsuitable cleaning agents.
l Damage caused by abnormal environmental or unsuitable
operating conditions.
l Damage resulting from improper transport.
2
Safety
2.1
Intended use
The Cool Top Trail 20G - 24G is designed for installation in cara-
vans or motorhomes and vehicles with living compartments.
The Cool Top Trail 20G - 24G:
l is not suitable for installation in construction machines, ag-
ricultural machines or similar equipment.
l is not intended to be used in boats or to be exposed to
strong vibrations.
l is not suitable for houses or apartments.
l may not be operated in vehicles while driving.
2.2
Safety information
DANGER
Danger of electrocution
u
Always switch off the mains power and disconnect
the mains before working on the system.
u
Make sure that the vehicle's external mains power
supply socket is effectively grounded in accordance
with the local regulations.
- Failure to ground the unit correctly may cause elec-
tric shock or fire.
u
Test the air conditioner for leakage current after in-
stallation.
u
Immediately turn off the air conditioner and isolate
power supply if you detect any unusual odour,
smoke or fire.
u
The T 5A 250 V fuse for the air conditioner is loc-
ated on the electronic control unit. Only replace this
with an identical fuse.
Introduction | 1
