CAUTION! Fire hazard
Place the fuses near the batteries to protect the cable from short circuits and possible burning.
NOTICE! Damage hazard
Do not reverse the polarity.
Observe the following instructions when connecting the charger:
• Use suitable measuring instruments:
Multimeter with DC voltage measurement, 200 V or autoscale
Amperometric clamp with direct measurement (100 A scale or higher)
• Use cables with a cross section of 6 mm.
• Always connect the charger before connecting the batteries.
• Do not use ferrules. Strip the cable ends as follows:
Signal cable: 12 mm (0.5 mm² ... 1.5 mm²)
Charging cable: 15 mm
Make the required connections to the charger.
9 Configuration
NOTICE! Damage hazard
Use a small screwdriver to carefully move the DIP switches to the required position.
Setting the charging program
NOTICE! Damage hazard
Only use batteries that are suitable for the specified charging voltage.
Select the charging program suitable for the type of house battery used based on the battery manufacturer's specifi-
cations, the information on the charging curves (see
data
). The specified charging times apply to an average ambient temperature of 20 °C.
Slide the DIP switches to the position shown in the table below to set the charging program for the respective
type of house battery.
Battery charging function
) and the technical data (see
EN
Technical
13
