Kärcher RCV 2 Oorspronkelijke Gebruiksaanwijzing pagina 18
Beschikbare talen
Beschikbare talen
Button
Instruction
Standby/charging mode: Press once to
start the all rooms cleaning with silent
mode. Press again to pause the task.
In standby/cleaning mode: Press once to
start the machine for recharging.
In recharge mode: Press once to pause.
In charging mode: Failure
In charging mode: Press once, the ma-
chine will fully backed out of the charging
station and rotated 180 ° to the right.
In non-charging mode: Press to switch to
manual control mode and the machine
moves forward; Release, machine
stopped.
In charging mode: Press once, the ma-
chine will fully backed out of the charging
station and rotated 180 ° to the right.
In non-charging mode: Press once to
switch to manual control mode, and the
machine rotates 180 ° to the right.
In charging mode: Press once, the ma-
chine will fully backed out of the charging
station and rotated 180 ° to the right.
In non-charging mode: Press to switch to
manual control mode, and the machine
will turn right; Release, machine
stopped.
In charging mode: Press once, the ma-
chine will fully backed out of the charging
station and rotated 180 ° to the right.
In non-charging mode: Press to switch to
manual control mode, and the machine
will turn left; Release, machine stopped.
In standby/charging mode: Press once to
start the all rooms cleaning. Press again
to pause the task.
In running mode: Press once to pause
the task.
Standby/charging mode: Press once to
start spiral cleaning of an area with a ra-
dius of 0.6m. Press again to stop the
task.
Standby/charging mode: Press once to
start cleaning along the wall. Press again
to stop the task.
With each press, the suction power in-
creases by one level, and after reaching
the highest level, it jumps to the lowest
level.
18
Button
Instruction
With each press, the water quantity in-
creases by one level, and after reaching
the highest level, it jumps to the lowest
level.
Note
● Remote controller use AAA battery.
● Non-rechargeable batteries are not to be recharged.
● Different types of batteries or new and used batter-
ies are not to be mixed.
● Batteries are to be inserted with the correct polarity.
● Exhausted batteries are to be removed from the ap-
pliance and safely disposed of.
● If the appliance is to be stored unused for a long pe-
riod, the batteries should be removed.
● The supply terminals are not to be short-circuited.
● Open the battery compartment cover on the back of
the remote control and remove/assemble the AAA
battery.
The cleaning robot automatically switches to sleep
mode after 5 minutes of inactivity. Press any button to
wake it up.
● The cleaning robot does not switch to sleep mode
when it is on the charging station.
● The cleaning robot switches off automatically if it is
in sleep mode for more than 6 hours
If the cleaning robot encounters an error during opera-
tion, the display flashes red and a signal sounds.
For a solution, see chapter .
If no action is taken within 5 minutes, the cleaning robot
automatically switches to sleep mode.
Installing the side brush
1. Turn the cleaning robot upside down.
2. Fit the side brush.
Illustration B
WARNING
● Only charge the appliance using the original charger
SAW12G-200-0600G enclosed or with a charger ap-
proved by KÄRCHER.
Use the following adapter:
● Appliance type: RCV 2
Power supply:
Docking Station 9.773-091.0
Setting up the charging station
WARNING
The RCV 2 cleaning robot may only be charged on the
charger of charging station 9.773-091.0 and charger
SAW12G-200-0600G.
● Select the location so that the cleaning robot can
easily reach the charging station.
English
Sleep mode
Error mode
Initial start-up
Charger
