● Ensure a distance of at least 0.5 m to the left and
right of the charging station and a distance of at
least 1.5 m in front of the charging station.
● The location must not be exposed to direct sunlight.
1. Set up the charging station.
Illustration C
2. Plug the mains cable device plug into the cable
holder on the side of the charging station.
Illustration D
3. Connect the mains plug.
Connecting the cleaning robot with the
charging station
Illustration E
1. Place the cleaning robot on the floor in front of the
charging station.
2. Press and hold the on/off switch for 3 seconds.
The cleaning robot switches on.
3. As soon as the display lights up, place the cleaning
robot manually on the charging station and make
sure that the charging contacts have a good contact.
After the initial start-up, the cleaning robot automatically
moves to the charging station.
Connecting cleaning robots with WLAN and
The cleaning robot can be controlled directly via buttons
on the device, Remote controller or via an App using a
WLAN-enabled mobile device.To be able to use all
available functions we recommended controlling the
cleaning robot via the Kärcher Home Robots App.
Before you download the App, make sure you have the
following:
● The mobile device is connected to the Internet.
● The 2.4 GHz WLAN of the router is activated.
● Sufficient WLAN coverage is guaranteed.
Note
It will more convenient to connect to the robot with the
Buletooth of the mobile opened.
Download the Kärcher Home Robots App from the Ap-
®
ple App Store
or from the Google Play™ store.
● Google Play™ and Android™ are trademarks or
registered trademarks of Google Inc.
®
● Apple
and App store
trademarks of Apple Inc.
The Kärcher Home Robots App offers the following
main functions, among others:
● Setting of time schedules
● Notes on faults or malfunctions and the cleaning
progress
● Setting of cleaning preferences (suction modes)
● Activation/deactivation of the "Do not disturb" mode
● FAQ with detailed troubleshooting
App
®
are trademarks or registered
● Contact details for the KÄRCHER Service Centres
Connecting the cleaning robot with the Kärcher
Home Robots App and WLAN:
1. Download the KÄRCHER Home&Garden App from
the Apple App Store or from the Google Play Store.
2. Open the Kärcher Home Robots App.
3. Create an account (if you are not already regis-
tered).
4. Add the desired cleaning robot.
5. Follow the step-by-step instructions in the App.
Installing 2-in-1 dust container with water
The 2-in-1 dust container with water reservoir may con-
tain a small amount of residual water due to quality con-
trol. This is normal.
Use the 2-in-1 dust container with water reservoir when
you want to clean both dry and wet.
For dry cleaning, remove the wiper cloth and the wiper
cloth holder, see chapter .
Illustration F
1. Push the 2-in-1 dust container with water reservoir
into position until it audibly latches into place.
Removing the 2-in-1 dust container with
1. Press the clamp.
2. Remove the 2-in-1 dust container with water reser-
voir.
Illustration G
Installing the wiper cloth holder with wiper
1. Attach the wiper cloth to the wiper cloth holder.
Illustration H
a Press the wiper cloth onto the wiper cloth holder.
b Press on the hook and loop strip.
2. Install the wiper cloth holder.
Illustration I
Removing the wiper cloth holder with wiper
1. Press any button.
The cleaning robot stops.
2. Remove the wiper cloth holder.
Illustration J
Reset WLAN connection
If you switch to a new router or change your WLAN
password, you must reset the cleaning robot's WLAN
connection.
Note
Only 2.4 GHz WLAN networks are supported.
1. Switch on the cleaning robot, see chapter .
2. Press the On/Off button and the "Return to charging
station" button simultaneously for 7 seconds until a
voice says: "Resetting the WLAN connection and
entering network configuration mode".
3. Connect the cleaning robot to the charging station,
see chapter .
Restoring the factory settings
1. Press and hold the "Return to charging station" but-
ton for 5 seconds until a signal sounds.
2. Press and hold the "Return to charging station" but-
ton again for 5 seconds until a signal sounds.
Factory settings are restored.
English
Initial startup
reservoir
water reservoir
cloth
cloth
19
