Pulsoxymeter
6. Installation
6.1 View of the front panel
Fig. 2 Front view
6.2 Battery
Step 1. Refer to Figure 3 and insert the two AAA size batteries properly in the right
direction.
Step 2. Replace the cover.
Please take care when you insert the
batteries for the improper insertion may
damage the device.
6.3 Mounting the Hanging Rope
Step 1. Put the end of the rope through the
hole.
Step 2. Put another end of the rope through the first one and then tighten it.
7. Operating Guide
1) Insert the two batteries properly to the direction, and then replace the cover.
2) Open the clip as shown in Figure 5.
3) Let the patient's finger put into the rubber cushions of the clip (make sure the
finger is in the right position), and then clip the finger.
4) Press the switch button once on front panel.
5) Do not shake the finger and keep the patient at ease during the process.
Meanwhile, human body is not recommended in movement status.
6) Get the information directly from screen display.
7) The device could change display direction according to the handing direction.
Fingernails and the luminescent tube should be on the same side.
Figure 5 Finger Position
23
Fig. 3 Batteries installation
EN
