ACCESSORIES/OPTIONS
In addition to the standard components, the machine can be equipped with the following accessories/options, according to the
machine speciÞ c use:
–
GEL/AGM batteries
–
Brushes and cylindrical brushes of different materials
–
Pads of different materials
–
Squeegee blades of different materials
–
Chemical Mixing System
–
Flashing light
–
Mop a trash kit
–
670 W vacuum system motor
For further information concerning the optional accessories, contact an authorised Retailer.
TECHNICAL DATA
Description
Cleaning width
Squeegee width
Solution/clean water tank capacity
Solution ß ow
Rear wheel diameter
Front wheel speciÞ c pressure on the ß oor
Rear wheel speciÞ c pressure on the ß oor
Front steering, driving and braking wheel diameter
Vacuum system motor power
Drive system motor power
Maximum speed
Maximum gradient when working
Sound pressure level at workstation
(ISO 11201, ISO 4871, EN 60335-2-72) (LpA)
Machine sound pressure level
(ISO 3744, ISO 4871, EN 60335-2-72) (LwA)
Vibration level at the operator's arms
(ISO 5349-1, EN 60335-2-72)
Vibration level at the operator's body
(ISO 2631-1, EN 60335-2-72)
Battery compartment size (length x width x height)
Battery type
Vacuum system capacity
Machine height
Machine maximum length
Minimum turning radius
Machine width without squeegee
Description
Brush/pad diameter
Weight without batteries and with empty tanks
Maximum weight with batteries, full tanks and operator (75 kg) (GVW)
Brush/pad motor power
Brush/pad-holder speed
Brush/pad-holder pressure with extra-pressure function turned off
Brush/pad-holder pressure with extra-pressure function turned on
9098960000(1)2011-04 A
Bedienungsanleitung auf www.gluesing.net
General technical data
Technical data for machines with brush/pad-holder deck
SCRUBTEC R 466 - R 471 - R 471C - BOOST
USER MANUAL
SCRUBTEC
SCRUBTEC
R 466
R 471
660 mm
710 mm
890 mm
80 litres
1 to 3 litres/min
250 mm
0.5 N/mm
0.9 N/mm
225 mm
420 W
300 W
6 km/h
2%
65 dB(A) ± 3 dB(A)
82 dB(A)
< 2.5 m/s
0.8 m/s
380 x 540 x 300 mm
No. 4 6 V batteries, 180 Ah C5 (WET)
4 6 V batteries, 180 Ah C5 (GEL/AGM)
1,000 mmH
1,230 mm
1,360 mm
1,500 mm
670 mm
748 mm
SCRUBTEC R 466
330 mm
175 kg
459 kg
2 x 400 W
230 rpm
30 kg
48 kg
®
R4
ENGLISH
SCRUBTEC
SCRUBTEC
R 471C
BOOST
®
R4
710 mm
710 mm
2
2
83 dB(A)
2
2
O
2
810 mm
730 mm
SCRUBTEC R 471
355 mm
177 kg
461 kg
32 kg
50 kg
9
