Instructions for the installer
3.7.2 Type of power supply
It is possible to obtain different connections according to the voltage, simply by moving the
unconnected cable ends on the terminal board as shown in the following diagrams.
According to the model, consult the table "C
COOKING HOB
COOKING HOB 4 / 6 / 8 BURNERS
COOKING HOB 4 / 6 BURNERS + B / T / C
COOKING HOB 4 BURNERS + B / T + C
INDUCTION HOB (5 ELEMENTS)
B = STEAK GRILL
T = FRY-TOP
C = VITROCERAMIC GRIDDLE
M
ODELS CONNECTED ACCORDING TO DIAGRAM
M
ODELS CONNECTED ACCORDING TO DIAGRAM
*
O
RIGINAL CONNECTION SET BY MANUFACTURER
ONNECTION TO THE TERMINAL BOARD
CONNECTION TO THE TERMINAL BOARD
Ⓐ
CAN BE COMMUTATED BY THE INSTALLER ACCORDING TO DIAGRAM
Ⓒ
CAN BE COMMUTATED BY THE INSTALLER ACCORDING TO DIAGRAM
".
POWER kW
POWER SUPPLY
0,006
DIAGRAM
2,4
4,8
7,4
DIAGRAM
Ⓒ
Ⓐ
Ⓑ
Ⓐ
91
