62
Note: The steamroom/steam
generator must NOT be used
during descaling!
Important! To prevent the steam generator from starting up while
it contains descaling agent, make sure unauthorised persons
do not have access to start the appliance during the descaling
process.
1
Control
panel
ON
3
Control
panel
OFF
Steam
generator
5
7
Figure 55 Follow the indicated steps when descaling the steam
generator
Instructions for descaling the Tylö Steam generator (See figures
55, 56):
1.
Start the steam generator.
2.
Wait for the steam to appear.
3.
Switch off the steam generator, first at the control panel and
then using the power switch.
4.
Wait for approx: 5 minutes.
5.
Unscrew the cover nut on the T-connector.
6.
Use a funnel to pour the descaling agent into the tank via the
T-connector.
7.
Tighten the cover nut on the T-connector.
8.
Leave the descaling agent to work for at least 60 minutes.
9.
The tank will be automatically drained and flushed when the
switch on the steam generator is turned on.
the switch is turned on, stay by the steam generator to ensu-
re that the automatic draining and flushing start.
After descaling, the tank should be drained and flushed. The
steam generator is then ready for use again.
If there is a large amount of limescale in the steam generator, it
will be necessary to perform descaling several times in immediate
succession.
2
4
5 min
6
8
60 min
9
Steam
generator
ON
Important! When
Figure 56 Use a funnel that is shaped in such a way that the des-
caling agent does not enter the steam pipe
Note: Descaling agent must
not enter the steam pipe.
Descaling agent must not under any circumstances enter the ste-
am pipe. There is a risk that sensitive materials (such as marble/
limestone) may be damaged if decalcifying agents are released
through the steam pipe while the steam generator is producing
steam. Use a funnel with a tube that passes the steam pipe (see
Figure 56) when the descaling agent is added.
