• Sawing straight and curved cuts as
well as mitre cuts (only wood and
plastic) of up to 45°
• Only operate in dry areas.
Please note the information on saw
blade types.
Any other use that is not expressly
permitted in this instruction manu-
al may pose a serious hazard to the
user and result in damage to the
device. The operator or user of the
machine is responsible for any acci-
dents or personal injury and/or ma-
terial damage to third parties or their
property. The machine is intended to
be used by do-it-yourselfers. It was
not designed for heavy commercial
use. The warranty is void in the case
of commercial use. The manufacturer
is not liable for damage caused by
improper use or incorrect operation.
Scope of delivery/
accessories
Unpack the device and check that
everything is present.
Dispose of the packaging material
properly.
• Cordless Circular Saw
• 1 Saw blade (pre-assembled)
• 1 Hex key (stowed on the device)
• Reducer piece
• Parallel guide
• Storage case
• Translation of the original instruc-
tions
The rechargeable battery and char-
ger are not included in delivery.
Overview
The illustrations for the
device can be found on
the front and back fold-
out page.
26
1 Switch lock
2 On/Off switch
3 Handle
4 Scale (Cutting depth)
5 Hex key
6 Retaining screw (Cutting depth)
7 Base plate
8 Auxiliary handle
9 Reducer piece
10 Parallel guide
11 Scale (Parallel guide)
12 Storage case
13 Clamping screw
14 Direction of rotation arrow
15 Clamping flange
16 Saw blade
17 Guard cover
18 Pull lever
19 Battery holder
20 Chip ejector
21 Spindle lock
22 Scale (Cutting angle)
23 Retaining screw (Cutting angle)
24 Reading mark (Cutting angle)
25 Mount (Parallel guide)
26 Retaining screw (Parallel guide)
27 Charger
28 Battery release
29 Battery
30 Charge level indicator
31 Button
(Fig. A)
32 Reading mark (Cutting depth)
33 Mounting flange
(Fig. C)
34 Guide notch (0°; 45°)
