EnGLIsH
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into a liquid.
Lower Guard
The lower guard should always rotate and close freely from
a fully open to fully closed position. Always check for correct
operation before cutting by fully opening the guard and letting
it close. If the guard closes slowly or not completely, it will need
cleaning or servicing. Do not use the saw until it functions
correctly. To clean the guard, use dry air or a soft brush to
remove all accumulated sawdust or debris from the path of
the guard and from around the guard spring. Should this not
correct the problem, it will need to be serviced by an authorized
service center.
Base Plate Adjustment (Fig. E, BB, CC)
Your base plate has been factory set to assure that the blade is
perpendicular to the base plate. If after extended use you need
to re-align the blade, follow the directions below:
adjusting For 90 Degree cuts
1. Return the saw to 0 degrees bevel.
2. Place the saw on its side, and retract the lower guard.
3. Set the depth of cut to 51 mm.
4. Loosen the bevel adjustment lever (Fig. CC,
square against the blade and the base plate as shown in
Figure BB.
5. Using a wrench
16
, turn the set screw
of the base plate until the blade and the base plate are
both in flush contact with the square. Retighten the bevel
adjustment lever.
Adjusting Bevel Adjustment Lever (Fig. CC)
It may be desirable to adjust the bevel adjustment lever
may loosen in time and hit the base plate before tighten ing.
To Tighten the Lever:
1. Hold the bevel adjustment lever
locknut
.
35
2. Adjust the bevel adjustment lever by rotating it in the
desired direction about 1/8 of a revolution.
3. Retighten nut.
Blades
A dull blade will cause inefficient cutting, overload on the
saw motor, excessive splintering and increase the possibility
of kickback. Change blades when it is no longer easy to push
the saw through the cut, when the motor is straining, or when
excessive heat is built up in the blade. It is a good practice to
keep extra blades on hand so that sharp blades are available for
immediate use. Dull blades can be sharpened in most areas.
Hardened gum on the blade can be removed with kerosene,
turpentine, or oven cleaner. Anti-stick coated blades can be
used in applications where excessive build-up is encountered,
such as pressure treated and green lumber.
44
7
). Place a
34
on the underside
7
. It
7
and loosen the
Optional Accessories
WARNING: Since accessories, other than those offered
by D
WALT, have not been tested with this product, use
e
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only D
accessories should be used with this product.
DO NOT USE WATER FEED ATTACHMENTS WITH THIS SAW.
VISUALLY EXAMINE CARBIDE BLADES BEFORE USE. REPLACE
IF DAMAGED.
Consult your dealer for further information on the
appropriate accessories.
Reducing Dust Exposure
Before starting work, check the hazard class of the dust that will
be produced when working.
WARNING: Avoid touching or breathing dust as it can
be harmful to health. Dust created when using a power
tool and when conducting other construction activities
can contain chemicals, minerals, or particles known to
cause respiratory infections, allergic reactions, cancer,
birth defects, or other reproductive harm of the user
or bystanders.
•
Such dust can be generated, for example, when working on
hardwoods such as beech or oak, lead-based paint, concrete,
masonry, or stones containing quartz.
•
Material containing asbestos may be handled only
by specialists.
•
Observe the relevant regulations in your country for the
materials to be worked on.
•
Use a dust extractor or extraction system with an officially
approved protection class in compliance with the locally
applicable dust protection regulations and suitable for the
material to be worked on.
•
Capture the resulting dust particles directly at the source and
avoid deposits in the surrounding area. Use suitable extraction
accessories for this purpose.
additional measures:
ʵ Make sure that the workplace is well ventilated.
ʵ Wear a respirator appropriate for the type of
dust generated.
Protecting the Environment
Products/batteries are recyclable, but if marked with the
crossed-out bin, they must not be disposed of with normal
household waste.
Run the batteries down completely and separate them, and
separate any light sources from the product if possible. It
is the user's responsibility to delete personal data from the
product. Then take the waste to an official waste collection
center or a participating retailer who will often accept it free of
charge. Packaging should be discarded based on the marked
WALT recommended
e
