USER MANUAL

MACHINE DESCRIPTION

Standard machine description
(See Fig. F)
1.
Seat
2.
Steering wheel
3.
Frame
4.
Bumpers
5.
Hopper hood
6.
Hopper
7.
Right side lid
8.
Main broom
9.
Engine hood
10. Side broom
11. Dashboard
12. Control levers
Description of the machine with roof
(See Fig. G)
1.
Seat
2.
Steering wheel
3.
Frame
4.
Bumpers
5.
Hopper hood
6.
Hopper
7.
Right side lid
8.
Main broom
9.
Engine hood
10. Side broom
11. Dashboard
12. Control levers
13. Roof
Frame
Rigid, composite supporting frame on rectangular plan,
consisting of electrically welded steel plates.
The mechanical components of the machine are suitably
sized, according to a 1.4÷1.5 factor, to withstand the dynamic
stress due to the machine operation (supporting frame, hubs,
axles, hopper supporting and lifting system, etc.).
Hopper
The hopper is fitted on the front side of the machine and
connected to the frame by means of a hinge.
A hydraulic cylinder lifts and overturns the hopper when the
waste is to be dumped at a height. The lower part has a
hinged skirt, operated by a hydraulic cylinder, which closes
the hopper while the waste is being dumped. The front side
has a fan operated by a motor. This fan creates a vacuum
inside the hopper and in the main broom compartment. Inside
it, there is a polyester closed pocket filter connected to an
electric filter shaker.
On the front right side there is a side broom whose rotation is
operated by a hydraulic motor, while its lifting and lowering
are operated by a hydraulic cylinder.
It is possible to install a side broom on the left side as well and
a third broom for corner cleaning.
6
Main broom
It consists of a sweeping roller whose rotation is operated by
a hydraulic motor and whose lifting and lowering are operated
by a hydraulic cylinder. It is automatically adjusted by the
self-levelling device.
Engine
The engine, Lombardini LGW 627, drives the hydraulic
system pumps.
Front wheels
Pneumatic wheels
Superelastic wheels
They are independent, fastened to the frame by means
of a hub with built-in brake drum. The brakes are
hydraulic. The parking brake is mechanical.
Rear wheel
Pneumatic wheel
Superelastic wheel
The rear wheel is the driving and steering wheel. The
steering is operated by a hydraulic cylinder connected to
the power steering. A hydrostatic variable delivery pump
with servoassisted control supplies a drive hydraulic
motor for forward and reverse gear.
Dashboard
Fitted on the upper part of the frame and under the steering
wheel, the dashboard houses the machine warning lights and
instrumentation.
Hydraulic system
In the first circuit a variable delivery pump feeds the drive
hydraulic motor (rear wheel). In the second circuit a gear
pump feeds a lever double-acting distributor. The distributor
operates the lifting cylinders and the broom motors.
All circuits are protected by suction filters and safety valves.
Electrical system
12V electrical system supplied by an alternator operated by
the motor. The circuits are protected by lamellar fuses housed
in a relevant fuse box.
33014812(1)2005-07 A
