Description of the supplied connectors
1
Pos. in fig.
1
2
3
4
5
6
7
8
• The EZA 80Ah or 130Ah power pack must only be connected
3
2
Description
1 BLUE Anderson socket (SB50B) for auxiliary load connection
1 RED Anderson socket (SB50R) for engine battery connection (16²
cable)
1 70A fuse to be placed on the positive end of the cable linking the
EZA power pack and the engine battery
4 SB50 Anderson terminal lugs for 16² cable
2 terminal lugs for solar panel / wind power unit
1 connection cable lug for D+
2 lugs for 16² cable
1 GREY Anderson socket (SB120) for inverter connection
using the supplied connection cables.
4
5
8
6
7
43
