14- Technical features
General features
Capacity: 80 Ah
Nominal voltage: 12V
Technology: LIFEPO4
Impedance: <30mΛ
Operational temperature: -20°C/+60°C
Storage temperature: -10°C/+45°C
Rate of discharge to empty: <3%/year
Integrated battery surveillance module: BMS
Maintenance interface: USB
Battery management: EZA App
Bluetooth module
Details of the changes on each charge/discharge line
Recording of events (SD memory card)
Possibility of coupling batteries (x4 max.)
Converter management
EURO 6 compatible
Protection
Protected charge lines
Protected discharge lines
Battery security in case of short circuit
Battery security in case of overcharging
Battery security in case of deep discharge
General features
Capacity: 130 Ah
Nominal voltage: 12V
Technology: LIFEPO4
Impedance: <30mΛ
Operational temperature: -20°C/+60°C
Storage temperature: -10°C/+45°C
Rate of discharge to empty: <3%/year
Integrated battery surveillance module: BMS
Maintenance interface: USB
Battery management: EZA App
Bluetooth module
Details of the changes on each charge/discharge line
Recording of events (SD memory card)
Possibility of coupling batteries (x4 max.)
Converter management
EURO 6 compatible
Protection
Protected charge lines
Protected discharge lines
Battery security in case of short circuit
Battery security in case of overcharging
Battery security in case of deep discharge
Technical features
Depth:
260 mm
Maintenance
Diagnostic plug connector
Alternator charge line
EURO 6 compatible charge line regulator: 0-70A (integrated)
Max. current: 70A
Max. charge voltage: 14.6V
Photovoltaic charge line
Integrated photovoltaic regulator: 12V/50A
Max. solar panel voltage: 22V
Line protection: 50A
Auxiliary load line
Max. external charger: 14.6V/70A
Line protection: 70A
Supply discharge line
Min. voltage: 10V
Max. voltage: 14.6V
Energy cut off: 9.8V
Line protection: 70A
Converter discharge line
Min. voltage: 10V
Energy cut off: 9.8V
Line protection: 150A
Max. constant current:150A/1800W
Surge current: 5mns 150A
Technical features
Depth:
380 mm
Maintenance
Diagnostic plug connector
Alternator charge line
EURO 6 compatible charge line regulator: 0-70A (integrated)
Max. current: 70A
Max. charge voltage: 14.6V
Photovoltaic charge line
Integrated photovoltaic regulator: 12V/50A
Max. solar panel voltage: 22V
Line protection: 50A
Auxiliary load line
Max. external charger: 14.6V/70A
Line protection: 70A
Supply discharge line
Min. voltage: 10V
Max. voltage: 14.6V
Energy cut off: 9.8V
Line protection: 70A
Converter discharge line
Min. voltage: 10V
Energy cut off: 9.8V
Line protection: 150A
Max. constant current:150A/1800W
Surge current: 5mns 150A
68
