IDENTIFIED PROBLEM
The motor is running but it
does not spray
The motor works but the
spray does not reach the
pressure or spraying is
irregular.
The motor runs
intermittently when
spraying.
The motor does not stop
when the handle is released.
The handle does not close
TECHNICAL CHARACTERISTICS
8
EMPTY NET WEIGHT
FULL NET WEIGHT
GROSS WEIGHT
RATED CAPACITY
MAXIMUM OPERATING PRESSURE
RESIDUAL VOLUME
OPEN PUMP FLOW
BATTERY (Lithium-Ion)
CHARGER:
Input
Output
MAXIMUM CHARGE TIME
OPERATING TEMPERATURE
MAXIMUM JET REACH
CODE
POINTS TO BE VERIFIED
Pump priming and clean the hydraulic circuit
The amount of fluid in the sprayer
The recommended working positions for each
nozzle
Cleaning the suction filter of the tank (Ref. 1463)
Hydraulic connections and leakages
Air in the hydraulic circuit
The condition of the nozzle
Check if the pump or the electronics are damaged
The selected nozzle has a nominal flow rate less
than that recommended in the nozzle table.
Cleaning the nozzle, its filter and handle filter. [3.5] Clean the filters if necessary
Check if the pump or the electronics are damaged
The amount of fluid in the sprayer
Cleaning the suction filter of the tank (Ref. 1463)
Air in the hydraulic circuit
Hydraulic connections and leakages
Check if the pump is damaged
The condition of the joints
Raise the appliance to table height and
place the handle in a lower height, with
the appliance switched on and the handle
activated. Hold this position for a few seconds.
To avoid this issue, once the equipment
has been cleaned, it is recommended to
fill it with two litres of clean water for its
subsequent storage.
Fill the sprayer with the product to be
sprayed
Use the nozzles and work positions
recommended in the nozzle selection
tables T.1 and T.2.
Clean the filter if necessary. According to
[3.5] and [3.6]
Tighten any joint if necessary
Stop the motor and restart the equipment to
spray a few seconds with the lance pointing
upwards
Replace the nozzle if damage is perceived
or considerable wear and tear is discerned.
Contact the distributor
Use the nozzles and work positions
recommended in the nozzle selection
tables T.1 and T.2.
Contact the distributor
Fill the sprayer with the product to be
sprayed
Clean the filter if necessary. According to
[3.5] and [3.6]
Stop the motor and restart the equipment to
spray a few seconds with the lance pointing
upwards
Tighten any joint if necessary
Contact the distributor
Change and grease the joints or the filter
with joints. [4.1]
e
10LT
3,7 Kg / 8.15 lb
13,7 Kg / 30.2 lb
4,3 Kg / 9.5 lb
10L- 2.5 US gal
5,5 bar / 80 PSI
≤ 40ml
1,5 l/min - 0,4 GPM (US)
12Vmax-10.8V x 2.6Ah
100/240
1A 50/60Hz
VAC
13V
1A
DC
3 hours
5 - 40 ºC / 41 - 104 ºF
8 m
83010
ACTIONS TO BE CARRIED OUT
e
15LT
4 Kg / 8.8 lb
19 Kg / 42 lb
4,6 Kg / 10.2 lb
15L- 4 US gal
83011
/ 15
