WARNING
The noise emission values can vary from
the specified values during the actual use
of the power tool, depending on the type
and the manner in which the electric tool is
used, and in particular the type of work-
piece being processed.
Try to keep the stress as low as possible. For exam-
ple: Limit working time. In doing so, all parts of the
operating cycle must be taken into account (such as
times in which the power tool is switched off or times
in which it is switched on, but is not running under a
load).
8
Unpacking
WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
• Open the packaging and carefully remove the
product.
• Remove the packaging material, as well as the
packaging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for trans-
port damage. Immediately report any damage to
the transport company that delivered the Product.
Later claims will not be recognised.
• If possible, keep the packaging until the expiry of
the warranty period.
• Familiarise yourself with the product by means of
the operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number
as well as type and year of manufacture for the
product.
9
Assembly
ATTENTION
Always make sure the product is fully assembled
before commissioning!
8
|
GB / IE / NI / CY / MT
WARNING
Pull out the mains plug before carrying out
any setting, servicing or repair work!
Tool required:
• Slotted screwdriver* (A)
• 1x open-ended spanner, AF 10/13 mm* (B)
• 1 x Allen key 3 mm* (C)
• 1 x Allen key 4 mm* (D)
• 1 x Allen key 5 mm* (E)
* = may not be included in the scope of delivery!
9.1
Assembling the saw table (7)
(Fig. 4-6)
1. Remove the wing nut (22), the locking handle (23),
the two washers and the clamping plate (24).
2. Then remove the two knurled nuts (7b), the U-rein-
forcement (7a) and the two countersunk screws
M6x18 from the saw table (7). Use the 4 mm Allen
key (D).
3. Guide the saw table (7) over the band saw blade
(17). Fasten it to the two screws on the frame (14)
with the clamping plate (24), the two washers, the
locking handle (23) and the wing nut (22).
4. Mount the U-reinforcement (7a) to the bottom of
the saw table (7) with two countersunk screws
M6x18 and two knurled nuts (7b). Use the 4 mm Al-
len key (D).
9.2
Which band saw blade to use
Check that the tool attachment is fitted securely.
Tool attachments that are not fitted correctly or se-
curely may come loose during operation and injure
you.
The band saw blade included in the scope of delivery
is intended for universal use. The following criteria
should be considered when selecting the band saw
blade:
• It is possible to cut tighter radii with a narrow band
saw blade than with a wide band saw blade.
• Use wide band saw blades to perform straight
cuts. This is important in particular when cutting
wood. The band saw blade has a tendency to fol-
low the wood grain and therefore deviates easily
from the desired position.
• Fine-toothed band saw blades cut more smoothly,
but also more slowly than coarse band saw blades.
• Only use undamaged band saw blades that are in
perfect condition. Band saw blades that are bent,
blunt or damaged in any other way can break.
