5. Loosen the end stop screw (31) and the counternut
(31a). Use the open-ended spanner AF 10/13 (B).
6. Turn the end stop screw (31) clockwise to lower the
end stop point or anti-clockwise to increase it.
7. Using an angle*, align the saw table (7) at a right-
angle to the band saw blade (17), put the end stop
screw (31) in the desired position and tighten the
counternut (31a) again. Use the open-ended span-
ner AF 10/13 (B).
* = may not be included in the scope of delivery!
9.8
Use as a stationary machine
(Fig. 1)
The product must be mounted on a workbench for
continuous use.
• The product must be securely installed, i.e. bolted
down on a workbench or fixed machine stand.
• There are fixing holes in the foot (9) for this pur-
pose.
1. Mark the drill holes.
– Place the product as it will be installed later.
– Mark the positions of the holes to be drilled on
the workbench.
These are predetermined by the holes in the
foot (9).
Installation close to the edge is recommended.
2. Drill the holes (at least 6.5 mm diameter) through
the workbench.
3. Place the product over the drilled holes congruent
with the holes in the foot (9) and insert suitable
screws* through the holes from above and tighten
them.
* = may not be included in the scope of delivery!
9.9
Extraction port set (16) (Fig. 2)
The product is equipped with an extraction port.
The extraction port set (16) has a diameter of 40 mm.
Connect a dust extractor when processing dusty mate-
rials.
ATTENTION
The dust extraction system must be suitable for the
material to be processed.
Use a special extraction device to extract particularly
harmful or carcinogenic dusts.
1. Connect the hose of a suitable dust extraction sys-
tem* (e.g. industrial hoover) directly to the ex-
traction port set (16).
* = may not be included in the scope of delivery!
9.10
Push rod retainer (32) (Fig. 11)
The push rod retainer (32) is pre-mounted on the frame
(14).
If unused, the push rod (21) must always be stowed in
the push stick retainer (32).
10 Operation
ATTENTION
Always make sure the product is fully assembled
before commissioning!
Note:
The product is equipped with a safety switch. This
means that the product cannot be switched on if the
doors are open or have not been closed properly.
Make sure that both safety switches (11a) engage
properly on the housing doors (11).
WARNING
Danger of injury!
The on/off switch and the safety switch must not be
locked!
–
Do not work with the product if the switches are
damaged.
–
Make sure the product is in working order before
each use.
WARNING
Always make sure that the tool attachment is fitted
correctly!
WARNING
Make sure that the tool attachment is suitable for the
material to be processed.
Note:
The product must be mounted on a workbench for
continuous use.
• Let the tool attachment reach full speed before
processing the workpiece.
• Select a tool attachment that corresponds to the
material to be processed.
• The saw table must be mounted correctly.
• Place the product in a stable location.
• Prior to commissioning, all covers and safety devic-
es must be mounted correctly. Damaged or illegible
stickers must be replaced.
