Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer
We hope your new product brings you much enjoy-
ment and success.
Note:
In accordance with the applicable product liability
laws, the manufacturer of this product assumes no lia-
bility for damage to the product or caused by the prod-
uct arising from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised
specialists
• Installing and replacing non-original spare parts
• Improper use
• Failures of the electrical system in the event of the
electrical regulations and VDE provisions 0100, DIN
57113 / VDE0113 not being observed.
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper
and economic operation of the product, for avoiding
danger, for minimising repair costs and downtimes and
for increasing the reliability and extending the service
life of the product. In addition to the safety instructions
in this operating manual, you must also observe the
regulations applicable to the operation of the product
in your country.
Familiarise yourself with all operating and safety in-
structions before using the product. Only operate the
product as described and for the specified areas of ap-
plication. Keep the operating manual in a good place
and hand over all documents when passing the prod-
uct on to third parties.
3
Product description (Fig. 1-19)
1.
Clamping screw
2.
Top band wheel
3.
Running surfaces (band saw blade)
4.
Band saw blade guard
5.
Top saw band guide
6.
Table inlay
7.
Saw table
7a.
U-reinforcement
7b.
Knurled nut
8.
Bottom band wheel
9.
Foot
10.
Door lock
11.
Housing doors
11a. Safety switch
12.
On/off switch
13.
Adjustment handle (top band wheel)
13a. Wing nut (top band wheel)
14.
Main frame
15.
Graduated scale (pivot range)
16.
Suction port
17.
Band saw blade
18.
Wing screw (band saw blade guide)
18a. Adjusting nut (band saw blade guide)
19.
Transverse cutting gauge
19a. Knurled nut
20.
Parallel stop
20a. Clamping bar
21.
Push stick
22.
Wing nut
23.
Locking handle
24.
Clamping plate
25.
Top support bearing
25a. Allen screw
26.
Top guide pins
26a. Allen screws
27.
Top retainer
27a. Allen screw (2x)
28.
Bottom support bearing
28a. Allen screw
29.
Bottom retainer
29a. Allen screw
30.
Bottom guide pins
30a. Allen screws
31.
End stop screw (saw table adjustment)
31a. Counternut (saw table adjustment)
32.
Push rod retainer
4
Scope of delivery (Fig. 1-3)
Item Quantity Designation
7.
1 x
Saw table
17.
1 x
Band saw blade (pre-assembled)
19.
1 x
Mitre gauge
20.
1 x
Parallel stop
21.
1 x
Push stick
A.
1 x
Slotted-head screwdriver
B.
1 x
Open-ended spanner, size 10/13
C.
1 x
Allen key, 3 mm
D.
1 x
Allen key, 4 mm
E.
1 x
Allen key, 5 mm
1 x
Band saw
1 x
Operating manual
5
Proper use
The band saw is used for the longitudinal and trans-
verse cutting of timbers or wood-like workpieces.
Round materials may only be cut using suitable hold-
ing devices.
WARNING
Do not use the product to cut materials other than
those described in the operating manual.
